THOMAS AND BETTS PCC42/M40S/CS90 PCC42/M40S/CS90 7TCA296170R0909 THOMAS AND BETTS COMPOSITE 90 ELBOW M40 SHORT THREAD View larger
Images are for illustrative purposes only. Please refer to data sheet for details

PCC42/M40S/CS90 7TCA296170R0909 THOMAS AND BETTS COMPOSITE 90 ELBOW M40 SHORT THREAD

PCC42/M40S/CS90

7TCA296170R0909

THOMAS AND BETTS

2 Pcs.

COMPOSITE 90 ELBOW M40 SHORT THREAD COMPOSITE FITTING 90º M40 SHORT THREAD

Automation > Screw connection for corrugated plastic hose
Adaptaflex cable protection and cable gland

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Built with a short metric profile, the Thomas And Betts PCC42/M40S/CS90 composite 90 elbow creates dependable right-angle transitions for conduit systems entering threaded equipment ports. Elbow connectors manage tight spatial constraints while protecting internal wiring bundles from sharp bends and environmental exposure. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • EAN: 5020963802614
  • Customs Tariff Number: 3917400090
  • Product Net Weight: 1.26 lb 571.429 g
  • Package Level 2 Units: 2 piece
  • Package Level 2 Width: 6 in 152 mm
  • Package Level 2 Height: 3 in 76 mm
  • Package Level 2 Depth / Length: 14 in 356 mm
  • Application: For Insertion into Threaded Entries or Knockout to Connect Conduit
  • Brand / Label: Adaptaflex
  • Cable Entry Position: M40 Thread
  • Color: Black
  • Construction Element: Course Profile
  • Material: Polyamide with Nickel Plated Brass Threads
  • Number of Batteries: 0
  • Product Name: PLASTIC FITTINGS OR TUBES
  • Product Type: Conduit Fitting with Metric Threads

More info

▲

Ordering

EAN:5020963802614
Customs Tariff Number:3917400090

Dimensions

Product Net Weight:1.26 lb
571.429 g

Container Information

Package Level 2 Units:2 piece
Package Level 2 Width:6 in
152 mm
Package Level 2 Height:3 in
76 mm
Package Level 2 Depth / Length:14 in
356 mm

Additional Information

Application:For Insertion into Threaded Entries or Knockout to Connect Conduit
Brand / Label:Adaptaflex
Cable Entry Position:M40 Thread
Color:Black
Construction Element:Course Profile
Material:Polyamide with Nickel Plated Brass Threads
Number of Batteries:0
Product Name:PLASTIC FITTINGS OR TUBES
Product Type:Conduit Fitting with Metric Threads
Size:NC 42mm
UPC:786210315300

Certificates and Declarations (Document Number)

Data Sheet, Technical Information:PCC42/M40S/CS90
Declaration of Conformity - CE:9AKK107492A9618
Instructions and Manuals:PCC42/M40S/CS90

Classifications

ETIM 6:EC001176 - Screw connection for corrugated plastic hose
ETIM 7:EC001176 - Screw connection for corrugated plastic hose
UNSPSC:39121311
WEEE Category:Product Not in WEEE Scope
IDEA Granular Category Code (IGCC):4441 >> Electrical fittings
