8WH3004-0AE00 SIEMENS Through-type terminals with quick-connect technology 4 connection points, Cross-sectio..
8WH3004-0AE00
30040
SIEMENS
50 Pcs.
Automation > Feed-through terminal block
Terminals
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Siemens part number 8WH3004-0AE00 is a through-type terminal with quick-connect technology designed to securely join and distribute electrical conductors inside control cabinets and distribution panels. Industrial terminal blocks organize wiring layouts and ensure reliable mechanical and electrical connectivity across complex automation systems.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- product designation: ALPHA FIX terminal blocks
- design of terminal / terminal levels internally linked: No
- General technical data terminal contact spacing: 5 mm
- operating voltage / rated value: 800 V
- Protection class combustibility class according to UL 94: V0
- Main circuit operational current / rated value: 18 A
- Appearance color: grey
- Number number of terminal levels: 1
- number of terminal points / per terminal level: 4
- ● minimum: 1.5 mm²
- ● maximum: 1.5 mm²
- ● minimum: 1.5 mm²
- ● maximum: 1.5 mm²
- ● with core end processing / minimum: 1.5 mm²
- ● with core end processing / maximum: 2 mm²
- ● without core end processing / minimum: 1.5 mm²
More info
▲Technical data
Additional data
| Product | |||||||||||||||||||||||||||||||||||||
| Article Number (Market Facing Number) | 8WH3004-0AE00 | ||||||||||||||||||||||||||||||||||||
| Product Description | Through-type terminals with quick-connect technology 4 connection points, Cross-section: 0.25-1.5 mm2, Width: 5.2mm, Color: gray | ||||||||||||||||||||||||||||||||||||
| Product family | Insulation displacement terminals | ||||||||||||||||||||||||||||||||||||
| Product Lifecycle (PLM) | PM300:Active Product | ||||||||||||||||||||||||||||||||||||
| Price data | |||||||||||||||||||||||||||||||||||||
| Region Specific PriceGroup / Headquarter Price Group | 12X / 1BT | ||||||||||||||||||||||||||||||||||||
| Surcharge for Raw Materials | None | ||||||||||||||||||||||||||||||||||||
| Metal Factor | None | ||||||||||||||||||||||||||||||||||||
| Delivery information | |||||||||||||||||||||||||||||||||||||
| Export Control Regulations | AL : N / ECCN : N | ||||||||||||||||||||||||||||||||||||
| Standard lead time ex-works | 7 Day/Days | ||||||||||||||||||||||||||||||||||||
| Net Weight (kg) | 0,014 Kg | ||||||||||||||||||||||||||||||||||||
| Packaging Dimension | 43,00 x 94,00 x 3,00 | ||||||||||||||||||||||||||||||||||||
| Package size unit of measure | MM | ||||||||||||||||||||||||||||||||||||
| Quantity Unit | 1 Piece | ||||||||||||||||||||||||||||||||||||
| Packaging Quantity | 1 | ||||||||||||||||||||||||||||||||||||
| Minimum order quantity | 50 | ||||||||||||||||||||||||||||||||||||
| Additional Product Information | |||||||||||||||||||||||||||||||||||||
| EAN | 4001869344836 | ||||||||||||||||||||||||||||||||||||
| UPC | 662643170207 | ||||||||||||||||||||||||||||||||||||
| Commodity Code | 85369010 | ||||||||||||||||||||||||||||||||||||
| LKZ_FDB/ CatalogID | LV10.2 | ||||||||||||||||||||||||||||||||||||
| Product Group | 5557 | ||||||||||||||||||||||||||||||||||||
| Group Code | P310 | ||||||||||||||||||||||||||||||||||||
| Country of origin | China | ||||||||||||||||||||||||||||||||||||
| Compliance with the substance restrictions according to RoHS directive | Since: 01.04.2006 | ||||||||||||||||||||||||||||||||||||
| Product class | B: return restricted, please contact your Siemens partner/contact | ||||||||||||||||||||||||||||||||||||
| WEEE (2012/19/EU) Take-Back Obligation | Yes | ||||||||||||||||||||||||||||||||||||
| REACH Art. 33 Duty to inform according to the current list of candidates |
| ||||||||||||||||||||||||||||||||||||
| Classifications | |||||||||||||||||||||||||||||||||||||
| |||||||||||||||||||||||||||||||||||||
ETIM data
ETIM: EC000897 - Feed-through terminal block
| Value | Unit | |
|---|---|---|
| Connectable conductor cross section fine-strand without cable end sleeve (EF007341) | ['1.5', '1.5'] | mm² |
| Connectable conductor cross section fine-strand with cable end sleeve (EF007339) | ['1.5', '1.5'] | mm² |
| Connectable conductor cross section solid-core (EF007337) | ['1.5', '1.5'] | mm² |
| Connectable conductor cross section multi-wired (EF007343) | ['1.5', '1.5'] | mm² |
| Rated current In (EF008250) | 17.5 | A |
| Rated voltage (EF000228) | 800 | V |
| Type of electrical connection 1 (EF002526) | Insulation displacement connection | |
| Type of electrical connection 2 (EF002527) | Insulation displacement connection | |
| Connection position (EF008219) | Above | |
| Number of levels (EF002659) | 1 | |
| Number of clamp positions per level (EF002660) | 4 | |
| Mounting method (EF000003) | DIN rail (top hat rail) 35 mm | |
| Material insulation body (EF007543) | Other | |
| Operating temperature (EF002393) | ['-25', '55'] | °C |
| Inflammability class of insulation material according to with UL94 (EF002521) | V0 | |
| Width/grid dimension (EF002522) | 5.2 | mm |
| Height at lowest possible mounting height (EF002523) | 39.3 | mm |
| Length (EF001438) | 94.0 | mm |
| Explosion-tested version 'Ex e' (EF008498) | false | |
| Closing plate required (EF002525) | false | |
| Colour (EF000007) | Grey | |
| Internally connected stages (EF002661) | false |
