SIEMENS 8WD4440-0EA2 8WD4440-0EA2 SIEMENS Siren element, multi-tone 102 dB, 8 tones + adjustable volume, black, 115 V AC, diamete.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

8WD4440-0EA2 SIEMENS Siren element, multi-tone 102 dB, 8 tones + adjustable volume, black, 115 V AC, diamete..

8WD4440-0EA2

44400

SIEMENS

1 Pcs.

Siren element, multi-tone 102 dB, 8 tones + adjustable volume, black, 115 V AC, diameter 70 mm

Automation > Acoustic module for signal tower
Commanding and signaling devices

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Technical data

Siren element, multi-tone 102 dB, 8 tones + adjustable volume, black, 115 V AC, diameter 70 mm
product brand nameSIRIUS
product designationSiren element
General technical data
product function adjustable acoustic signalYes
type of voltage of the operating voltageAC
operating voltage
● 1 at AC at 50 Hz rated value115 V
● 1 at AC at 60 Hz rated value115 V
relative positive tolerance of the operating voltage10 %
relative negative tolerance of the operating voltage-10 %
consumed current maximum45 mA
tone frequency
● 10.9 kHz
● 23.5 kHz
reference code
● according to EN 61346-2P
● according to IEC 81346-2P
Acoustic signal
type of acoustic signal8 tones
service life of acoustic signal device5 000 h
loudness level102 dB
loudness level92 ... 102 dB
tone frequency of alternating tone0.9 ... 2.8 kHz
Enclosure
height54 mm
width70 mm
outer diameter of the signal column element70 mm
materialPC
colorblack
fastening methodBayonet
protection class IPIP65
Ambient conditions
ambient temperature during operation-20 ... +50 °C
Certificates/ approvals

Downloads and manuals

General Product ApprovalEMCDeclaration of Conformity

Confirmation

UL

EAC

RCM

EC/EU-Declaration of Conformity

UK Declaration of Conformity

other

Confirmation

Further information
Information- and Downloadcenter (Catalogs, Brochures,…)
Industry Mall (Online ordering system)
Cax online generator
Service&Support (Manuals, Certificates, Characteristics, FAQs,...)
Image database (product images, 2D dimension drawings, 3D models, device circuit diagrams, EPLAN macros, ...)
last modified:12/23/2020
Date
5/14/2022		Subject to change without notice
© Copyright Siemens 2022


Additional data

Product
Article Number (Market Facing Number)8WD4440-0EA2
Product DescriptionSiren element, multi-tone 102 dB, 8 tones + adjustable volume, black, 115 V AC, diameter 70 mm
Product family8WD44 signaling columns, 70 mm diameter
Product Lifecycle (PLM)PM300:Active Product
Price data
Region Specific PriceGroup / Headquarter Price Group41J / 41J
Surcharge for Raw MaterialsNone
Metal FactorNone
Delivery information
Export Control RegulationsAL : N / ECCN : N
Standard lead time ex-works2 Day/Days
Net Weight (kg)0,092 Kg
Packaging Dimension76,00 x 76,00 x 113,00
Package size unit of measureMM
Quantity Unit1 Piece
Packaging Quantity1
Additional Product Information
EAN4011209497474
UPC754554781365
Commodity Code85318070
LKZ_FDB/ CatalogIDCC-IC10
Product Group5833
Group CodeR711
Country of originGermany
Compliance with the substance restrictions according to RoHS directiveSince: 01.07.2006
Product classA: Standard product which is a stock item could be returned within the returns guidelines/period.
WEEE (2012/19/EU) Take-Back ObligationYes
REACH Art. 33 Duty to inform according to the current list of candidates

Information obligation imposed by Article 33, REACH Regulation: This product includes one or several articles in which the following substance of the candidate list is contained in concentrations higher than 0,1% weight by weight (w/w):

Lead titanium zirconium oxide

Based on the information currently available, we assume that these substances do not pose any risk if the articles are used as intended (including disposal). Please also refer to product documentation.

Information obligation imposed by Article 33, REACH Regulation: This product includes one or several articles in which the following substance of the candidate list is contained in concentrations higher than 0,1% weight by weight (w/w):

Lead

Based on the information currently available, we assume that these substances do not pose any risk if the articles are used as intended (including disposal). Please also refer to product documentation.

Classifications
VersionClassification
eClass627-37-12-37
eClass7.127-37-12-37
eClass827-37-12-37
eClass927-37-12-37
eClass9.127-37-12-37
ETIM5EC001261
ETIM6EC001261
ETIM7EC001261
ETIM8EC001261
IDEA44766
UNSPSC1439-12-15-34
UNSPSC1539-12-15-34

ETIM data

ETIM: EC001261 - Acoustic module for signal tower

Value Unit
Degree of protection (NEMA) (EF011959) -
Function (EF000030) Other
Outer diameter (EF000015) 70.0mm
Colour (EF000007) Black
Operating voltage at AC 50 Hz (EF008206) ['-', '-']V
Operating voltage at AC 60 Hz (EF008207) ['-', '-']V
Operating voltage at DC (EF008208) ['-', '-']V
Voltage type (EF000187) AC / AC
Tone adjustable (EF005920) true
Degree of protection (IP) (EF005474) IP65
Loudness (EF000144) 102dB
