8UD1771-2CF05 SIEMENS handle with masking plate EMERGENCY-STOP illuminated size 75x 75, for shaft 8x 8, test..
8UD1771-2CF05
17712
SIEMENS
1 Pcs.
Automation > Accessories/spare parts for low-voltage switch technology
3KD Switch-disconnectors, 3KC Power Switches
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An illuminated emergency-stop handle with masking plate, such as the Siemens 8UD1771-2CF05, provides manual operator control and immediate visual status indication on industrial control cabinet doors. Panel builders integrate these assemblies with internal disconnect shafts to ensure reliable mechanical safety shutdowns during emergency conditions.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- product designation: handle with masking plate
- design of the product: EMERGENCY OFF
- design of handle: Red-yellow
- design of the door lock system: Door interlocking
- length of handle: 45 mm
- protection class IP: IP65
- Product details product description: with illumination
- product feature / interlock: Yes
- ● extension shaft: No
- ● handle for emergency-OFF function: Yes
- product feature / lockable: Yes
- Accessories accessories: Handle with masking frame
- display version / for switch position indicator: test-0-I
- Mechanical Design height: 84 mm
- width: 84 mm
- depth: 80 mm
More info
▲Technical data
Additional data
| Product | ||||||||||||||||||||||||||||||||||
| Article Number (Market Facing Number) | 8UD1771-2CF05 | |||||||||||||||||||||||||||||||||
| Product Description | handle with masking plate EMERGENCY-STOP illuminated size 75x 75, for shaft 8x 8, test-0-I, handle size 45mm accessory for 3KD size 1 and 2, 3KF size 1 | |||||||||||||||||||||||||||||||||
| Product family | Ordering Data Overview | |||||||||||||||||||||||||||||||||
| Product Lifecycle (PLM) | PM300:Active Product | |||||||||||||||||||||||||||||||||
| Price data | ||||||||||||||||||||||||||||||||||
| Region Specific PriceGroup / Headquarter Price Group | 12P / 1CL | |||||||||||||||||||||||||||||||||
| Surcharge for Raw Materials | None | |||||||||||||||||||||||||||||||||
| Metal Factor | None | |||||||||||||||||||||||||||||||||
| Delivery information | ||||||||||||||||||||||||||||||||||
| Export Control Regulations | AL : N / ECCN : N | |||||||||||||||||||||||||||||||||
| Standard lead time ex-works | 2 Day/Days | |||||||||||||||||||||||||||||||||
| Net Weight (kg) | 0,178 Kg | |||||||||||||||||||||||||||||||||
| Packaging Dimension | 84,00 x 84,00 x 80,00 | |||||||||||||||||||||||||||||||||
| Package size unit of measure | MM | |||||||||||||||||||||||||||||||||
| Quantity Unit | 1 Piece | |||||||||||||||||||||||||||||||||
| Packaging Quantity | 1 | |||||||||||||||||||||||||||||||||
| Additional Product Information | ||||||||||||||||||||||||||||||||||
| EAN | 4001869525556 | |||||||||||||||||||||||||||||||||
| UPC | Not available | |||||||||||||||||||||||||||||||||
| Commodity Code | 85389099 | |||||||||||||||||||||||||||||||||
| LKZ_FDB/ CatalogID | LV10.1 | |||||||||||||||||||||||||||||||||
| Product Group | 5378 | |||||||||||||||||||||||||||||||||
| Group Code | P360 | |||||||||||||||||||||||||||||||||
| Country of origin | Germany | |||||||||||||||||||||||||||||||||
| Compliance with the substance restrictions according to RoHS directive | Since: 01.06.2012 | |||||||||||||||||||||||||||||||||
| Product class | A: Standard product which is a stock item could be returned within the returns guidelines/period. | |||||||||||||||||||||||||||||||||
| WEEE (2012/19/EU) Take-Back Obligation | No | |||||||||||||||||||||||||||||||||
