3SU1250-0EB20-0AA0 SIEMENS Pushbutton, compact, with extended stroke (12 mm), 22 mm, round, metal, red, push..
3SU1250-0EB20-0AA0
12500
SIEMENS
1 Pcs.
Automation > Front element for push button
Commanding and signaling devices
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
A Siemens 3SU1250-0EB20-0AA0 pushbutton is a complete compact unit featuring an extended stroke design for specialized tactile feedback on industrial panels. Extended stroke operators are often utilized where operators wear heavy protective gloves or require distinct travel confirmation.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- product designation: Pushbuttons
- design of the product: Complete unit
- product type designation: 3SU1
- product line: Metal, shiny, 22 mm
- Enclosure number of command points: 1
- Actuator design of the actuating element: Flat button with extended stroke
- principle of operation of the actuating element: momentary contact type
- ● light source: No
- ● contact module: Yes
- color of the actuating element: red
- material of the actuating element: plastic
- shape of the actuating element: round
- outer diameter of the actuating element: 29.5 mm
- Front ring product component front ring: Yes
- design of the front ring: Standard
- material of the front ring: Metal, high gloss
More info
▲Technical data
Additional data
| Product | |||||||||||||||||||||||||||||||||||||
| Article Number (Market Facing Number) | 3SU1250-0EB20-0AA0 | ||||||||||||||||||||||||||||||||||||
| Product Description | Pushbutton, compact, with extended stroke (12 mm), 22 mm, round, metal, red, pushbutton, flat, momentary contact type, with holder | ||||||||||||||||||||||||||||||||||||
| Product family | Actuators and indicators, 22 mm, metal, shiny | ||||||||||||||||||||||||||||||||||||
| Product Lifecycle (PLM) | PM300:Active Product | ||||||||||||||||||||||||||||||||||||
| Price data | |||||||||||||||||||||||||||||||||||||
| Region Specific PriceGroup / Headquarter Price Group | 41J / 41J | ||||||||||||||||||||||||||||||||||||
| Surcharge for Raw Materials | None | ||||||||||||||||||||||||||||||||||||
| Metal Factor | None | ||||||||||||||||||||||||||||||||||||
| Delivery information | |||||||||||||||||||||||||||||||||||||
| Export Control Regulations | AL : N / ECCN : N | ||||||||||||||||||||||||||||||||||||
| Standard lead time ex-works | 55 Day/Days | ||||||||||||||||||||||||||||||||||||
| Net Weight (kg) | 0,105 Kg | ||||||||||||||||||||||||||||||||||||
| Packaging Dimension | 50,00 x 120,00 x 30,00 | ||||||||||||||||||||||||||||||||||||
| Package size unit of measure | MM | ||||||||||||||||||||||||||||||||||||
| Quantity Unit | 1 Piece | ||||||||||||||||||||||||||||||||||||
| Packaging Quantity | 1 | ||||||||||||||||||||||||||||||||||||
| Additional Product Information | |||||||||||||||||||||||||||||||||||||
| EAN | 4011209973930 | ||||||||||||||||||||||||||||||||||||
| UPC | 804766073212 | ||||||||||||||||||||||||||||||||||||
| Commodity Code | 85389099 | ||||||||||||||||||||||||||||||||||||
| LKZ_FDB/ CatalogID | CC-IC10 | ||||||||||||||||||||||||||||||||||||
| Product Group | 5452 | ||||||||||||||||||||||||||||||||||||
| Group Code | R711 | ||||||||||||||||||||||||||||||||||||
| Country of origin | China | ||||||||||||||||||||||||||||||||||||
| Compliance with the substance restrictions according to RoHS directive | Since: 01.10.2014 | ||||||||||||||||||||||||||||||||||||
| Product class | A: Standard product which is a stock item could be returned within the returns guidelines/period. | ||||||||||||||||||||||||||||||||||||
| WEEE (2012/19/EU) Take-Back Obligation | Yes | ||||||||||||||||||||||||||||||||||||
| REACH Art. 33 Duty to inform according to the current list of candidates |
| ||||||||||||||||||||||||||||||||||||
| Classifications | |||||||||||||||||||||||||||||||||||||
| |||||||||||||||||||||||||||||||||||||
ETIM data
ETIM: EC000221 - Front element for push button
| Value | Unit | |
|---|---|---|
| Degree of protection (NEMA), front side (EF011961) | - | |
| With protective cover (EF005500) | - | |
| Labelled (EF001537) | - | |
| Colour button (EF000190) | Red | |
| Number of command positions (EF001372) | 1 | |
| Construction type lens (EF006253) | Round | |
| Hole diameter (EF000079) | 22.3 | mm |
| Width opening (EF004565) | 29.5 | mm |
| Height opening (EF004778) | 20.3 | mm |
| Type of button (EF001546) | Other | |
| Suitable for illumination (EF001142) | false | |
| Switching function latching (EF007447) | FALSE | |
| Spring-return (EF001407) | FALSE | |
| With front ring (EF006014) | true | |
| Material front ring (EF005972) | Metal | |
| Colour front ring (EF002429) | Other | |
| Degree of protection (IP), front side (EF003118) | Other |
