3SU1032-2BF10-0AA0 SIEMENS Selector switch, illuminable, 22 mm, round, plastic with metal front ring, black,..
3SU1032-2BF10-0AA0
10322
SIEMENS
1 Pcs.
Selector switch, illuminable, 22 mm, round, plastic with metal front ring, black, selector switch, short, 2 switch positions O-I, latching, actuating angle 90°, 10:30h/13:30h
Automation > Front element for selector switch
Commanding and signaling devices
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲ETIM: EC000222 - Front element for selector switch
| Value | Unit | |
|---|---|---|
| Type of control element (EF006976) | - | |
| Number of switch positions (EF000231) | 2 | |
| Suitable for illumination (EF001142) | true | |
| Colour control element (EF007167) | Black | |
| Colour indicator light cap (EF007165) | Other | |
| Construction type lens (EF006253) | Rectangular | |
| Hole diameter (EF000079) | 22.3 | mm |
| Width opening (EF004565) | 32.3 | mm |
| Height opening (EF004778) | 28.8 | mm |
| Switching function latching (EF007447) | FALSE | |
| Spring-return (EF001407) | FALSE | |
| With front ring (EF006014) | true | |
| Material front ring (EF005972) | Metal | |
| Colour front ring (EF002429) | Grey | |
| Degree of protection (IP), front side (EF003118) | IP68 | |
| Degree of protection (NEMA) (EF011959) | 4X |
| Product | ||||||||||||||||||||||||||||||||||
| Article Number (Market Facing Number) | 3SU1032-2BF10-0AA0 | |||||||||||||||||||||||||||||||||
| Product Description | Selector switch, illuminable, 22 mm, round, plastic with metal front ring, black, selector switch, short, 2 switch positions O-I, latching, actuating angle 90°, 10:30h/13:30h | |||||||||||||||||||||||||||||||||
| Product family | Actuators and indicators, 22 mm, plastic with metal front ring, matte | |||||||||||||||||||||||||||||||||
| Product Lifecycle (PLM) | PM300:Active Product | |||||||||||||||||||||||||||||||||
| Price data | ||||||||||||||||||||||||||||||||||
| Price Group | 41J | |||||||||||||||||||||||||||||||||
| Surcharge for Raw Materials | None | |||||||||||||||||||||||||||||||||
| Metal Factor | None | |||||||||||||||||||||||||||||||||
| Delivery information | ||||||||||||||||||||||||||||||||||
| Export Control Regulations | AL : N / ECCN : N | |||||||||||||||||||||||||||||||||
| Standard lead time ex-works | 1 Day/Days | |||||||||||||||||||||||||||||||||
| Net Weight (kg) | 0,020 Kg | |||||||||||||||||||||||||||||||||
| Product Dimensions (W x L x H) | Not available | |||||||||||||||||||||||||||||||||
| Packaging Dimension | 30,00 x 60,00 x 30,00 | |||||||||||||||||||||||||||||||||
| Package size unit of measure | MM | |||||||||||||||||||||||||||||||||
| Quantity Unit | 1 Piece | |||||||||||||||||||||||||||||||||
| Packaging Quantity | 1 | |||||||||||||||||||||||||||||||||
| Additional Product Information | ||||||||||||||||||||||||||||||||||
| EAN | 4047621016795 | |||||||||||||||||||||||||||||||||
| UPC | 804766474521 | |||||||||||||||||||||||||||||||||
| Commodity Code | 85389099 | |||||||||||||||||||||||||||||||||
| LKZ_FDB/ CatalogID | CC-IC10 | |||||||||||||||||||||||||||||||||
| Product Group | 5452 | |||||||||||||||||||||||||||||||||
| Group Code | R711 | |||||||||||||||||||||||||||||||||
| Country of origin | Czech Republic | |||||||||||||||||||||||||||||||||
| Compliance with the substance restrictions according to RoHS directive | Since: 01.10.2014 | |||||||||||||||||||||||||||||||||
| Product class | A: Standard product which is a stock item could be returned within the returns guidelines/period. | |||||||||||||||||||||||||||||||||
| WEEE (2012/19/EU) Take-Back Obligation | Yes | |||||||||||||||||||||||||||||||||
| REACH Art. 33 Duty to inform according to the current list of candidates |
| |||||||||||||||||||||||||||||||||
| Classifications | ||||||||||||||||||||||||||||||||||
| ||||||||||||||||||||||||||||||||||
