3NE8724-1 SIEMENS SITOR fuse link, with Bolt-on links, NH000, In: 160 A, aR, Un AC: 690 V, Un DC: 440 V, fro..
3NE8724-1
87241
SIEMENS
10 Pcs.
Automation > Low Voltage HRC fuse
SITOR Extra-fast Fuses
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
A Siemens SITOR fuse link is engineered specifically for semiconductor protection, offering high-speed interruption capabilities to protect sensitive electronics like power converters and inverters. These specialized fuses are essential components in advanced industrial drive systems. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- product designation: SITOR fuse link
- design of the product: With bolt-on links
- design of an identification indicator: front indicator
- design of the switching contact: With bolt-on links, silver-plated
- design of the fuse link: SITOR, LV HRC design
- operating class of the fuse link: aR
- varying load factor (WL): 0.9
- type of voltage / of the operating voltage: AC/DC
- ● at AC / rated value: 690 V
- ● at DC: 440 V
- ● at DC / according to IEC 60947-2 / rated value: 50 kA
- ● according to IEC 60947-2 / rated value: 200 kA
- Dissipation power loss [W]: 31 W
- ● maximum: 31 W
- ● at 30 °C / rated value: 160 A
- ● at 40 °C / rated value: 160 A
More info
▲Technical data
Additional data
| Product | ||||||||||||||||||||||||||||||||||
| Article Number (Market Facing Number) | 3NE8724-1 | |||||||||||||||||||||||||||||||||
| Product Description | SITOR fuse link, with Bolt-on links, NH000, In: 160 A, aR, Un AC: 690 V, Un DC: 440 V, front indicator | |||||||||||||||||||||||||||||||||
| Product family | LV HRC Design | |||||||||||||||||||||||||||||||||
| Product Lifecycle (PLM) | PM300:Active Product | |||||||||||||||||||||||||||||||||
| Price data | ||||||||||||||||||||||||||||||||||
| Region Specific PriceGroup / Headquarter Price Group | 15I / 1DM | |||||||||||||||||||||||||||||||||
| Surcharge for Raw Materials | None | |||||||||||||||||||||||||||||||||
| Metal Factor | LHP----- | |||||||||||||||||||||||||||||||||
| Delivery information | ||||||||||||||||||||||||||||||||||
| Export Control Regulations | AL : N / ECCN : N | |||||||||||||||||||||||||||||||||
| Standard lead time ex-works | 2 Day/Days | |||||||||||||||||||||||||||||||||
| Net Weight (kg) | 0,146 Kg | |||||||||||||||||||||||||||||||||
| Packaging Dimension | 60,00 x 105,00 x 24,00 | |||||||||||||||||||||||||||||||||
| Package size unit of measure | MM | |||||||||||||||||||||||||||||||||
| Quantity Unit | 1 Piece | |||||||||||||||||||||||||||||||||
| Packaging Quantity | 1 | |||||||||||||||||||||||||||||||||
| Minimum order quantity | 10 | |||||||||||||||||||||||||||||||||
| Additional Product Information | ||||||||||||||||||||||||||||||||||
| EAN | 4011209457409 | |||||||||||||||||||||||||||||||||
| UPC | 040892553192 | |||||||||||||||||||||||||||||||||
| Commodity Code | 85361090 | |||||||||||||||||||||||||||||||||
| LKZ_FDB/ CatalogID | LV10.1 | |||||||||||||||||||||||||||||||||
| Product Group | 5540 | |||||||||||||||||||||||||||||||||
| Group Code | P310 | |||||||||||||||||||||||||||||||||
| Country of origin | China | |||||||||||||||||||||||||||||||||
| Compliance with the substance restrictions according to RoHS directive | Since: 01.07.2006 | |||||||||||||||||||||||||||||||||
| Product class | B: return restricted, please contact your Siemens partner/contact | |||||||||||||||||||||||||||||||||
| WEEE (2012/19/EU) Take-Back Obligation | Yes | |||||||||||||||||||||||||||||||||
| REACH Art. 33 Duty to inform according to the current list of candidates |
| |||||||||||||||||||||||||||||||||
| Classifications | ||||||||||||||||||||||||||||||||||
| ||||||||||||||||||||||||||||||||||
ETIM data
ETIM: EC000055 - Low Voltage HRC fuse
| Value | Unit | |
|---|---|---|
| Voltage type (EF000187) | - | |
| Insulated metal gripping lugs (IMGL) (EF012538) | - | |
| Construction size (EF002566) | NH000 | |
| Rated current (EF000227) | 160 | A |
| Rated voltage (EF000228) | 690 | V |
| Rated switching capacity (EF002563) | 200.0 | kA |
| Utilization category (EF002572) | aR (accompanied semiconductor protection) | |
| Type of fuse status indicator (EF004473) | Top fuse status indicator |
