SIEMENS 3NE8717-1 3NE8717-1 SIEMENS SITOR fuse link, with Bolt-on links, NH000, In: 50 A, gR, Un AC: 690 V, Un DC: 440 V, fron.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

3NE8717-1 SIEMENS SITOR fuse link, with Bolt-on links, NH000, In: 50 A, gR, Un AC: 690 V, Un DC: 440 V, fron..

3NE8717-1

87171

SIEMENS

10 Pcs.

SITOR fuse link, with Bolt-on links, NH000, In: 50 A, gR, Un AC: 690 V, Un DC: 440 V, front indicator SET OF FUSES SITOR (DIN 43653, TAM.00 COMPACT) 50A, AC 690V, MED. FIX. 80MM ( ** ATTENTION : Price per 1 Unit and Minimum Quantity / Order Multiple 10 Units ** ). Cancelations and returns limited. Consult conditions.

Automation > Low Voltage HRC fuse
SITOR Extra-fast Fuses

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Technical data

SITOR fuse link, with Bolt-on links, NH000, In: 50 A, gR, Un AC: 690 V, Un DC: 440 V, front indicator
Model
product brand nameSENTRON
product designationSITOR fuse link
design of the productWith bolt-on links
design of an identification indicatorfront indicator
design of the switching contactWith bolt-on links, silver-plated
design of the fuse linkSITOR, LV HRC design
General technical data
size of fuse system / according to EN 60269-1NH000
operating class of the fuse linkgR
varying load factor (WL)0.9
type of voltage / of the operating voltageAC/DC
Supply voltage
supply voltage
● at AC / rated value690 V
● at DC440 V
Switching capacity
switching capacity current
● at DC / according to IEC 60947-2 / rated value50 kA
● according to IEC 60947-2 / rated value200 kA
Dissipation
power loss [W]15 W
power loss [W]
● for rated value of the current / at AC / in hot operating state / per pole15 W
● maximum15 W
Current
operational current
● at 30 °C / rated value50 A
● at 40 °C / rated value50 A
● at 45 °C / rated value50 A
● at 50 °C / rated value49.5 A
● at 55 °C / rated value49 A
● at 60 °C / rated value48.5 A
● at AC / rated value50 A
Product details
product descriptionNot non-interchangeable
Mechanical Design
mounting positionAny, preferably vertical
Environmental conditions
ambient temperature / during operation
● minimum-20 °C
● maximum50 °C
environmental category-20 to +50 at 95% relative humidity

Downloads and manuals

General Product ApprovalDeclaration of Conformity

CSA

Confirmation

UR

EAC

EC/EU-Declaration of Conformity

UK Declaration of Conformity

other

Miscellaneous

Further information
Information- and Downloadcenter (Catalogs, Brochures,…)
Industry Mall (Online ordering system)
Service&Support (Manuals, Certificates, Characteristics, FAQs,...)
Image database (product images, 2D dimension drawings, 3D models, device circuit diagrams, ...)
CAx-Online-Generator
Tender specifications
Date
5/10/2022


Additional data

Product
Article Number (Market Facing Number)3NE8717-1
Product DescriptionSITOR fuse link, with Bolt-on links, NH000, In: 50 A, gR, Un AC: 690 V, Un DC: 440 V, front indicator
Product familyLV HRC Design
Product Lifecycle (PLM)PM300:Active Product
Price data
Region Specific PriceGroup / Headquarter Price Group15I / 1DM
Surcharge for Raw MaterialsNone
Metal FactorLHP-----
Delivery information
Export Control RegulationsAL : N / ECCN : N
Standard lead time ex-works2 Day/Days
Net Weight (kg)0,144 Kg
Packaging Dimension60,00 x 100,00 x 24,00
Package size unit of measureMM
Quantity Unit1 Piece
Packaging Quantity1
Minimum order quantity10
Additional Product Information
EAN4011209457355
UPC887621829612
Commodity Code85361050
LKZ_FDB/ CatalogIDLV10.1
Product Group5540
Group CodeP310
Country of originChina
Compliance with the substance restrictions according to RoHS directiveSince: 01.07.2006
Product classB: return restricted, please contact your Siemens partner/contact
WEEE (2012/19/EU) Take-Back ObligationYes
REACH Art. 33 Duty to inform according to the current list of candidates

Information obligation imposed by Article 33, REACH Regulation: This product includes one or several articles in which the following substance of the candidate list is contained in concentrations higher than 0,1% weight by weight (w/w):

Lead

Based on the information currently available, we assume that these substances do not pose any risk if the articles are used as intended (including disposal). Please also refer to product documentation.

Classifications
VersionClassification
eClass627-14-20-05
eClass7.127-14-20-05
eClass827-14-20-05
eClass927-14-20-05
eClass9.127-14-20-05
ETIM5EC000055
ETIM6EC000055
ETIM7EC000055
ETIM8EC000055
UNSPSC1539-12-16-26

ETIM data

ETIM: EC000055 - Low Voltage HRC fuse

Value Unit
Voltage type (EF000187) -
Insulated metal gripping lugs (IMGL) (EF012538) -
Construction size (EF002566) NH000
Rated current (EF000227) 50A
Rated voltage (EF000228) 690V
Rated switching capacity (EF002563) 200.0kA
Utilization category (EF002572) gR (general purpose semiconductor protection)
Type of fuse status indicator (EF004473) Top fuse status indicator
