3NC3343-6U SIEMENS SITOR fuse link, with female thread on both sides, NH3, In: 1250 A, aR, Un AC: 800 V, Un ..
3NC3343-6U
33436
SIEMENS
3 Pcs.
SITOR fuse link, with female thread on both sides, NH3, In: 1250 A, aR, Un AC: 800 V, Un DC: 440 V, front indicator
SITOR FUSE 1250A AR 800V MBC=6XIN ( ** ATTENTION : Price per 1 Unit and Minimum Quantity / Order Multiple 3 Units ** ). Manufactured to order. Non-Cancelable Non-Returnable.
Automation > Low Voltage HRC fuse
SITOR Extra-fast Fuses
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
A Siemens Sitor fuse link is deployed in high-capacity industrial electrical environments to offer precise overcurrent protection for solid-state conversion devices and heavy-duty drives. This fuse handles extreme electrical loads reliably. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Product Article Number (Market Facing Number): 3NC3343-6U
- Product family: LV HRC Design
- Product Lifecycle (PLM): PM300:Active Product
- Metal Factor: LHP-----
- Delivery information Export Control Regulations: AL : N / ECCN : N
- Standard lead time ex-works: 3 Day/Days
- Net Weight (kg): 0,965 Kg
- Packaging Dimension: 100,00 x 255,00 x 86,00
- Package size unit of measure: MM
- Quantity Unit: 1 Piece
- Packaging Quantity: 1
- Minimum order quantity: 3
- Additional Product Information EAN: 4001869502823
- UPC: Not available
- Commodity Code: 85361090
- LKZ_FDB/ CatalogID: LV10.1
More info
▲| Product | ||||||||||||||||||||||||||||||||||||||||
| Article Number (Market Facing Number) | 3NC3343-6U | |||||||||||||||||||||||||||||||||||||||
| Product Description | SITOR fuse link, with female thread on both sides, NH3, In: 1250 A, aR, Un AC: 800 V, Un DC: 440 V, front indicator | |||||||||||||||||||||||||||||||||||||||
| Product family | LV HRC Design | |||||||||||||||||||||||||||||||||||||||
| Product Lifecycle (PLM) | PM300:Active Product | |||||||||||||||||||||||||||||||||||||||
| Price data | ||||||||||||||||||||||||||||||||||||||||
| Region Specific PriceGroup / Headquarter Price Group | 15I / 52G | |||||||||||||||||||||||||||||||||||||||
| Surcharge for Raw Materials | None | |||||||||||||||||||||||||||||||||||||||
| Metal Factor | LHP----- | |||||||||||||||||||||||||||||||||||||||
| Delivery information | ||||||||||||||||||||||||||||||||||||||||
| Export Control Regulations | AL : N / ECCN : N | |||||||||||||||||||||||||||||||||||||||
| Standard lead time ex-works | 3 Day/Days | |||||||||||||||||||||||||||||||||||||||
| Net Weight (kg) | 0,965 Kg | |||||||||||||||||||||||||||||||||||||||
| Packaging Dimension | 100,00 x 255,00 x 86,00 | |||||||||||||||||||||||||||||||||||||||
| Package size unit of measure | MM | |||||||||||||||||||||||||||||||||||||||
| Quantity Unit | 1 Piece | |||||||||||||||||||||||||||||||||||||||
| Packaging Quantity | 1 | |||||||||||||||||||||||||||||||||||||||
| Minimum order quantity | 3 | |||||||||||||||||||||||||||||||||||||||
| Additional Product Information | ||||||||||||||||||||||||||||||||||||||||
| EAN | 4001869502823 | |||||||||||||||||||||||||||||||||||||||
| UPC | Not available | |||||||||||||||||||||||||||||||||||||||
| Commodity Code | 85361090 | |||||||||||||||||||||||||||||||||||||||
| LKZ_FDB/ CatalogID | LV10.1 | |||||||||||||||||||||||||||||||||||||||
| Product Group | 5540 | |||||||||||||||||||||||||||||||||||||||
| Group Code | P310 | |||||||||||||||||||||||||||||||||||||||
| Country of origin | Greece | |||||||||||||||||||||||||||||||||||||||
| Compliance with the substance restrictions according to RoHS directive | Since: 01.01.2014 | |||||||||||||||||||||||||||||||||||||||
| Product class | C: products manufactured / produced to order, which cannot be reused or re-utilized or be returned against credit. | |||||||||||||||||||||||||||||||||||||||
| WEEE (2012/19/EU) Take-Back Obligation | Yes | |||||||||||||||||||||||||||||||||||||||
| REACH Art. 33 Duty to inform according to the current list of candidates |
| |||||||||||||||||||||||||||||||||||||||
| SCIP number | ||||||||||||||||||||||||||||||||||||||||
| Classifications | ||||||||||||||||||||||||||||||||||||||||
| ||||||||||||||||||||||||||||||||||||||||
