View larger
3NC3336-1U SIEMENS SITOR fuse link, with slotted blade contacts, NH3, In: 630 A, aR, Un AC: 1000 V, Un DC: 4..
3NC3336-1U
33361
SIEMENS
3 Pcs.
Automation > Low Voltage HRC fuse
SITOR Extra-fast Fuses
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Engineered for demanding industrial environments, this Siemens 3NC3336-1U SITOR fuse link offers reliable semiconductor protection in high-voltage power conversion setups. Heavy-duty slotted-blade fuses are routinely integrated into large-scale industrial drives and rectifier assemblies.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Product Article Number (Market Facing Number): 3NC3336-1U
- Product family: LV HRC Design
- Product Lifecycle (PLM): PM300:Active Product
- Metal Factor: LHP-----
- Delivery information Export Control Regulations: AL : N / ECCN : N
- Standard lead time ex-works: 3 Day/Days
- Net Weight (kg): 1,081 Kg
- Packaging Dimension: 270,00 x 200,00 x 105,00
- Package size unit of measure: MM
- Quantity Unit: 1 Piece
- Packaging Quantity: 1
- Minimum order quantity: 3
- Additional Product Information EAN: 4001869502694
- UPC: Not available
- Commodity Code: 85361090
- LKZ_FDB/ CatalogID: LV10.1
More info
▲| Product | ||||||||||||||||||||||||||||||||||||||||
| Article Number (Market Facing Number) | 3NC3336-1U | |||||||||||||||||||||||||||||||||||||||
| Product Description | SITOR fuse link, with slotted blade contacts, NH3, In: 630 A, aR, Un AC: 1000 V, Un DC: 440 V, front indicator | |||||||||||||||||||||||||||||||||||||||
| Product family | LV HRC Design | |||||||||||||||||||||||||||||||||||||||
| Product Lifecycle (PLM) | PM300:Active Product | |||||||||||||||||||||||||||||||||||||||
| Price data | ||||||||||||||||||||||||||||||||||||||||
| Region Specific PriceGroup / Headquarter Price Group | 15I / 52G | |||||||||||||||||||||||||||||||||||||||
| Surcharge for Raw Materials | None | |||||||||||||||||||||||||||||||||||||||
| Metal Factor | LHP----- | |||||||||||||||||||||||||||||||||||||||
| Delivery information | ||||||||||||||||||||||||||||||||||||||||
| Export Control Regulations | AL : N / ECCN : N | |||||||||||||||||||||||||||||||||||||||
| Standard lead time ex-works | 3 Day/Days | |||||||||||||||||||||||||||||||||||||||
| Net Weight (kg) | 1,081 Kg | |||||||||||||||||||||||||||||||||||||||
| Packaging Dimension | 270,00 x 200,00 x 105,00 | |||||||||||||||||||||||||||||||||||||||
| Package size unit of measure | MM | |||||||||||||||||||||||||||||||||||||||
| Quantity Unit | 1 Piece | |||||||||||||||||||||||||||||||||||||||
| Packaging Quantity | 1 | |||||||||||||||||||||||||||||||||||||||
| Minimum order quantity | 3 | |||||||||||||||||||||||||||||||||||||||
| Additional Product Information | ||||||||||||||||||||||||||||||||||||||||
| EAN | 4001869502694 | |||||||||||||||||||||||||||||||||||||||
| UPC | Not available | |||||||||||||||||||||||||||||||||||||||
| Commodity Code | 85361090 | |||||||||||||||||||||||||||||||||||||||
| LKZ_FDB/ CatalogID | LV10.1 | |||||||||||||||||||||||||||||||||||||||
| Product Group | 5540 | |||||||||||||||||||||||||||||||||||||||
| Group Code | P310 | |||||||||||||||||||||||||||||||||||||||
| Country of origin | Greece | |||||||||||||||||||||||||||||||||||||||
| Compliance with the substance restrictions according to RoHS directive | Since: 01.01.2014 | |||||||||||||||||||||||||||||||||||||||
| Product class | C: products manufactured / produced to order, which cannot be reused or re-utilized or be returned against credit. | |||||||||||||||||||||||||||||||||||||||
| WEEE (2012/19/EU) Take-Back Obligation | Yes | |||||||||||||||||||||||||||||||||||||||
| REACH Art. 33 Duty to inform according to the current list of candidates |
| |||||||||||||||||||||||||||||||||||||||
| SCIP number | ||||||||||||||||||||||||||||||||||||||||
| Classifications | ||||||||||||||||||||||||||||||||||||||||
| ||||||||||||||||||||||||||||||||||||||||
