SCAME 815.2365B 815.2365B SCAME TERMINAL BLOCK T85 25mmq 750V AC WHITE View larger
Images are for illustrative purposes only. Please refer to data sheet for details

815.2365B SCAME TERMINAL BLOCK T85 25mmq 750V AC WHITE

815.2365B

8152365

SCAME

15 Pcs.

TERMINAL BLOCK T85 25mmq 750V AC WHITE T85 25mmq 750V AC WHITE STRIP 25mm² WHITE

Automation > Single- and multi-pole terminal strip
CONNECTO Series Terminal strips

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Utilized extensively in industrial control panels, this Scame 815.2365B terminal block provides an organized method for joining and distributing electrical circuits safely. Panel builders rely on insulated terminal strips to manage multiple wiring connections in machinery and electrical distribution units.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Synthetical description: TERMINAL BLOCK T85
  • Connecting capacity: 25mm²
  • Rated voltage: 750V
  • Pitch: 17,5mm
  • Ø fixing hole: 4,3mm
  • Colour: WHITE
  • Material: BRASS
  • Dimensions: 210x38x36mm
  • Commercial Series: CONNECTO Series

More info

▲
Commercial Series
CONNECTO Series
Synthetical description
TERMINAL BLOCK T85
Connecting capacity
25mm²
Rated voltage
750V
Dimensions
210x38x36mm
Pitch
17,5mm
Ø fixing hole
4,3mm
Colour
WHITE
Material
BRASS
Catalogue notes
Self-extinguishing material in compliance with IEC 60695-2-1 standard 850°C.
Engineering plastic casing
Max. service temperature - continuous duty: 85°C.
Brass terminal
12 poles
Captive screws of zinc-plated steel


Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
