SCAME 659.DB5243-08 659.DB5243-08 SCAME PILLAR DOMINO-OMNIA S.STEEL IP66 32A View larger
Images are for illustrative purposes only. Please refer to data sheet for details

659.DB5243-08 SCAME PILLAR DOMINO-OMNIA S.STEEL IP66 32A

659.DB5243-08

524308

SCAME

1 Pcs.

PILLAR DOMINO-OMNIA S.STEEL IP66 32A DOMINO-OMNIA INOX IP66 32A 400V TURRET IP66 3P+N+E 32A 400V 487x1235x375mm

Automation > Light/energy pole
Distribution assemblies - SCAME

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Constructed for heavy-duty outdoor utility, the Scame 659.DB5243-08 is a stainless steel distribution turret equipped with robust protection mechanisms. Industrial operations and infrastructure projects rely on this equipment to distribute safe power efficiently across expansive sites. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Synthetical description: PILLAR DOMINO-OMNIA S.STEEL
  • Material: STAINLESS STEEL [AISI316L]
  • Colour: GREY
  • Protection degree IP: IP66
  • Protection degree IK: IK10
  • Mounting version: ON TURRET
  • Rated current: 32A
  • Rated voltage: 400V
  • Working frequency: 50/60Hz
  • Poles: 3P+N+E
  • Hour position: 6h
  • Typology: Stationary distrib.assemblies
  • Inlet supply unit: Terminal block 16mm²
  • RCD protection: Main switch with RCD
  • No. of available outlets: 4 NR
  • In disp. ing/tipo apparecchio: MCB 4P 32A

More info

▲
Commercial Series
KIOSK Series
Synthetical description
PILLAR DOMINO-OMNIA S.STEEL
Material
STAINLESS STEEL [AISI316L]
Colour
GREY
Dimensions
487x1235x375mm
Protection degree IP
IP66
Protection degree IK
IK10
Mounting version
ON TURRET
Rated current
32A
Rated voltage
400V
Working frequency
50/60Hz
Poles
3P+N+E
Hour position
6h
Typology
Stationary distrib.assemblies
Inlet supply unit
Terminal block 16mm²
RCD protection
Main switch with RCD
No. of available outlets
4 NR
In disp. ing/tipo apparecchio
MCB 4P 32A
