SCAME 623.2000-006 623.2000-006 SCAME MULTIPLE ADAPTER 1x32A+2xGERMAN View larger
Images are for illustrative purposes only. Please refer to data sheet for details

623.2000-006 SCAME MULTIPLE ADAPTER 1x32A+2xGERMAN

623.2000-006

623.2000-006

SCAME

1 unit


Automation > Adaptors for industrial applications
ADAPTO Series 3-4 Way without cable

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Scame multiple adapter 623.2000-006 is a portable distribution assembly built to expand power access on temporary job sites. Portable distribution units allow crews to branch out higher-amperage feeds into multiple usable workstation receptacles effortlessly. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Synthetical description: MULTI -WAY ADAPTOR
  • Material: THERMOPLASTIC
  • Colour: GREY
  • Protection degree IP: IP44/IP54
  • Mounting version: PORTABLE
  • Rated current: 32A
  • Rated voltage: 380V
  • Working frequency: 60Hz 50Hz
  • Poles: 3P+N+E
  • Typology: Portable distribut. assemblies
  • Inlet supply unit: Plug IEC 309 3P+N+E 32A
  • Version: With cable and plug
  • Emergency push button: Not applicable
  • RCD protection: Not applicable
  • No. of available outlets: 3 NR
  • In disp. ing/tipo apparecchio: Not applicable

More info

▲
Commercial Series
ADAPTO Series
Synthetical description
MULTI -WAY ADAPTOR
Material
THERMOPLASTIC
Colour
GREY
Dimensions
200x150x80mm
Protection degree IP
IP44/IP54
Mounting version
PORTABLE
Rated current
32A
Rated voltage
380V
Working frequency
60Hz
50Hz
Poles
3P+N+E
Typology
Portable distribut. assemblies
Inlet supply unit
Plug IEC 309 3P+N+E 32A
Version
With cable and plug
Emergency push button
Not applicable
RCD protection
Not applicable
No. of available outlets
3 NR
In disp. ing/tipo apparecchio
Not applicable
Max power gen.
Not applicable
Catalogue notes
Plug OPTIMA-REVERSE with phase inverter.
