PHOENIX CONTACT ZEC 1,5/6-ST-5,0BKC2R1,6PW:1-6 ZEC 1,5/6-ST-5,0BKC2R1,6PW:1-6 1707330 PHOENIX CONTACT PCB connector, nominal current: 10 A, rated voltage (.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

ZEC 1,5/6-ST-5,0BKC2R1,6PW:1-6 1707330 PHOENIX CONTACT PCB connector, nominal current: 10 A, rated voltage (..

ZEC 1,5/6-ST-5,0BKC2R1,6PW:1-6

1707330

PHOENIX CONTACT

2000 Pcs.

PCB connector, nominal current: 10 A, rated voltage (III/2): 320 V, nominal cross section: 1.5 mm², number of positions: 6, pitch: 5 mm, connection method: Spring-cage connection, color: signal violet, contact surface: Tin, mounting: Direct plug-in method Direct connector for printed circuit board, nominal section: 1.5 mm², color: black, nominal current: 10 A, nominal voltage (III/2): 320 V, contact surface: Tin, contact connection type: Female, number of potentials: 6, number of rows: 1, number of poles: 6, number of connections: 6, family of articles: ZEC 1.5/.. -ST, pitch: 5 mm, connection type: Spring connection, mounting: Direct plug-in connection technology, driver/printed circuit board connection direction: 0 °, plug-in system: ZEC, locking: Snap-in lock, fixing type: Snap-in flange

Cables > Cable connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1707330
Packing unit1 pc
GTIN4046356919296
Weight per Piece (excluding packing)200.000 g
Custom tariff number85366930
Country of originGR (Greece)

Drawings

Diagram

Diagram
Type: ZEC 1,5/...-ST-5,0

Back to top

Dimensions

Pitch5 mm
Back to top

General

Range of articlesZEC 1,5/..-ST
Number of positions6
Nominal cross section1.5 mm²
Back to top

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
Back to top

Classifications

eCl@ss

eCl@ss 4.027260700
eCl@ss 4.127260700
eCl@ss 5.027260700
eCl@ss 5.127260700
eCl@ss 6.027260700
eCl@ss 7.027440309
eCl@ss 8.027440309
eCl@ss 9.027440309
Back to top

ETIM

ETIM 4.0EC002638
ETIM 5.0EC002638
ETIM 6.0EC002638
ETIM 7.0EC002638
Back to top

UNSPSC

UNSPSC 13.239121409
UNSPSC 18.039121409
UNSPSC 19.039121409
UNSPSC 20.039121409
UNSPSC 21.039121409
Back to top

ETIM for 1707330 Connectors (EC002638)
Feature Name Feature Value
Type of connection (EF000064) Other
Contact type (EF001587) Bus
Number of poles (EF001391) 6
Number of plug-in contact rows (EF006935) 1
Modular spacing contacts (EF007326) 5 mm
Modular spacing connections (EF006827) 5 mm
Angle contact/conductor connection (EF007546) Other
Rated current In (EF008250) 10 A
Rated voltage (EF000228) 320 V
Rated surge voltage (EF002993) 4 kV
Over voltage category (EF006785) III
Pollution degree (EF006786) 2
Connectable conductor cross section fine-strand without cable end sleeve (EF007341) 0.2 mm²
Connectable conductor cross section fine-strand with cable end sleeve (EF007339) 0.25 mm²
Connectable conductor cross section solid-core (EF007337) 0.2 mm²
Type of electric connection (EF003961) Spring clamp connection
Connectable cable type (EF006816) Tubular cable
Material of contact surface (EF004020) Tin
Material contact (EF007544) Copper
Material insulation body (EF007543) Polyamide (PA)
Housing material (EF001596) Other
Housing colour (EF000136) Black
Inflammability class of insulation material according to UL94 (EF002521) V0
Operating temperature (EF002393) -40 °C
