View larger
Images are for illustrative purposes only. Please refer to data sheet for details
ZEC 1,5/ 4-ST-5,0 C3,R1,4 1712426 PHOENIX CONTACT Printed-circuit board connector
ZEC 1,5/ 4-ST-5,0 C3,R1,4
1712426
PHOENIX CONTACT
50 Pcs.
Printed-circuit board connector
Direct connector for printed circuit board, nominal section: 1.5 mm², color: green, nominal current: 10 A, dimensioning voltage (III/2): 320 V, contact surface: Tin, contact type: Female connection, Number of potentials: 4, Number of rows: 1, Number of poles per row: 4, number of connections: 4, family of articles: ZEC 1.5/.. -ST, pitch: 5 mm, connection type: Spring connection, mounting: Direct plug-in connection technique, conductor connection direction/printed circuit board: 0 °, Stecksystem: ZEC, Locking: Snap lock, packaging type: boxed
Cables > Cable connector
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲General
| Range of articles | ZEC 1,5/..-ST |
|---|---|
| Number of positions | 4 |
| Connection method | Spring-cage connection |
| Insulating material group | I |
| Rated voltage (III/2) | 320 V |
| Nominal current IN | 10 A |
| Nominal cross section | 1.5 mm² |
| Flammability rating according to UL 94 | V0 |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
