View larger
Images are for illustrative purposes only. Please refer to data sheet for details
MSTBV 2,5/ 5-GF-5,08 GNTQ 1707727 PHOENIX CONTACT Base housing, rated current: 12 A, number of poles: 5, pit..
MSTBV 2,5/ 5-GF-5,08 GNTQ
1707727
PHOENIX CONTACT
50 Pcs.
Base housing, rated current: 12 A, number of poles: 5, pitch: 5.08 mm, color: turquoise green, contact surface: Tin, mounting: Wave solder
Printed circuit board base housing, nominal section: 2.5 mm², color: turquoise green, nominal current: 12 A, nominal voltage (III/2): 320 V, contact surface: Tin, contact type: Male, number of potentials: 5, number of rows: 1, number of poles: 5, number of connections: 5, family of articles: MSTBV 2.5/.. -GF, pitch: 5.08 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 3.9 mm, number of solder pins per potential: 1, plug-in system: COMBICON MSTB 2.5, Plug-in face orientation: Standard, locking: Screw lock, fixing type: Air clamping (thread), packaging type: boxed
Connectors > Printed circuit board connector
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Header, nominal current: 12 A, number of positions: 5, pitch: 5.08 mm, color: turquoise green, contact surface: Tin, mounting: Wave soldering
Your advantages
Maximum flexibility when it comes to device design – one header for connectors with different connection technologiesWell-known mounting principle allows worldwide useVertical connection enables multi-row arrangement on the PCBScrewable flange for superior mechanical stability
General
| Range of articles | MSTBV 2,5/..-GF |
|---|---|
| Rated voltage (III/3) | 250 V |
| Connection in acc. with standard | EN-VDE |
| Nominal current IN | 12 A |
| Color | turquoise green |
| Number of positions | 5 |
Environmental Product Compliance
| China RoHS | Environmentally Friendly Use Period = 50 |
|---|---|
| For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
