View larger
Images are for illustrative purposes only. Please refer to data sheet for details
WEBVISIT 6 PRO 2700949 PHOENIX CONTACT Software
WEBVISIT 6 PRO
2700949
PHOENIX CONTACT
1 Pcs.
Software
WebVisit 6 is the engineering tool for creating Web visualizations for all control systems with integrated web server. The Pro variant contains functions such as alarm lists, trends, user management, URL breaks and other favorite functions.
Automation > Visualization software
Automation Software (AS)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Key Commercial Data
| Orderkey | 2700949 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 59 (C-6-2017) |
| GTIN | 4046356661232 |
| Weight per Piece (excluding packing) | 81.000 g |
| Custom tariff number | 85234910 |
| Country of origin | DE (Germany) |
License information
| Intended use for the software | Web editor |
|---|---|
| Type of license | Development license |
| Information regarding the type of license | Unlimited scope, with macro library |
Functions
| Basic functions | The user interface has a functional design and even the basic version offers numerous graphic basic elements and functions. |
|---|---|
| The variables needed for visualization are imported directly from PC Worx. | |
| Number of I/O nodes | not relevant |
| Control system | (Target system) Embedded controller |
Hardware requirements
| Hard disk | min. 2 GByte |
|---|---|
| RAM | min. 2 GByte |
| CPU | min. Intel®Pentium®4 / Celeron®1,6 GHz |
| Optical drive | DVD-ROM |
| Monitor resolution | XGA (1024 x 768) |
| Operating equipment | Keyboard, mouse |
Software requirements
| Operating system | Windows®7 Professional SP1 (32-Bit/64-Bit) |
|---|---|
| Windows®7 Ultimate SP1 (32-Bit/64-Bit) | |
| Windows®8.1 Professional (32-Bit/64-Bit) | |
| Windows®8.1 Enterprise (32-Bit/64-Bit) | |
| Windows®10 (32-Bit/64-Bit) | |
| Languages supported | German, English, French |
| Supported browsers | Internet Explorer Version 8 or later |
Classifications
eCl@ss 4.027248001eCl@ss 4.127248001eCl@ss 5.027242502eCl@ss 5.127242500eCl@ss 6.027242500eCl@ss 7.027242502eCl@ss 8.027242502eCl@ss 9.027242502
| Feature Name | Feature Value |
|---|---|
| With OPC-interface, server (EF003172) | No |
| With OPC-interface, client (EF003173) | No |
| With programming interfaces (EF003174) | No |
| Multi-user capable, runtime (EF003152) | No |
| Max. number of clients (EF003154) | 0 |
| Suitable for web-clients (EF003155) | No |
| SCADA functionality (EF007458) | No |
| Alarm-management (EF006805) | Yes |
| Trend representation (EF007510) | Yes |
| Online projecting possible (EF003158) | No |
| Language switch possible (EF007493) | No |
| With script language Visual Basic (EF003163) | No |
| With other script language (EF003164) | No |
| Library with object elements (EF003165) | Not available |
| User groups (password protection) possible (EF003166) | No |
| Function process diagnostics (EF003170) | Not available |
| Min. required processor speed for runtime system (EF003175) | 1600000000 GHz |
| Min. required processor speed for configuration software (EF003181) | 1600000000 GHz |
