View larger
Images are for illustrative purposes only. Please refer to data sheet for details
VS-25-A-DEVNET-LV 1653061 PHOENIX CONTACT D-SUB contact insert
VS-25-A-DEVNET-LV
1653061
PHOENIX CONTACT
1 Pcs.
D-SUB contact insert
Connectors > Contact insert for rectangular connectors
Field Device Connectors (FDC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Key Commercial Data
| Orderkey | 1653061 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 24 (PC-2005) |
| GTIN | 4017918970017 |
| Weight per Piece (excluding packing) | 8.500 g |
| Custom tariff number | 85369010 |
| Country of origin | DE (Germany) |
Mechanical characteristics
| Number of positions | 5 |
|---|---|
| Connection method | Solder connection |
| Type of contact | Pin |
| Degree of protection | IP67 |
Material data
| Flammability rating according to UL 94 | V0 |
|---|---|
| Housing material | PA |
| Contact carrier material | PBT |
| Contact material | Cu alloy |
| Contact surface material | gold-plated |
Electrical characteristics
| Number of positions | 5 |
|---|---|
| Rated current | 8 A |
| Overvoltage category | III |
| Degree of pollution | 3 |
| Rated voltage (III/3) | 250 V |
Environmental Product Compliance
| China RoHS | Environmentally Friendly Use Period = 50 |
|---|---|
| For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
