PHOENIX CONTACT TVFKCL 1,5/ 3-ST CP13BD:-A1 SO TVFKCL 1,5/ 3-ST CP13BD:-A1 SO 1704695 PHOENIX CONTACT Plug-in part, rated current: 10 A, number of poles: 3.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

TVFKCL 1,5/ 3-ST CP13BD:-A1 SO 1704695 PHOENIX CONTACT Plug-in part, rated current: 10 A, number of poles: 3..

TVFKCL 1,5/ 3-ST CP13BD:-A1 SO

1704695

PHOENIX CONTACT

50 Pcs.

Plug-in part, rated current: 10 A, number of poles: 3, pitch: 5 mm, connection type: Push-in spring connection, color: green, contact surface: Tin Connector for printed circuit board, nominal section: 1.5 mm², color: green, nominal current: 10 A, dimensioning voltage (III/2): 320 V, contact surface: Tin, contact type: Female connection, number of potentials: 3, number of rows: 1, number of poles: 3, number of connections: 6, family of articles: TVFKCL 1.5/.. -ST, pitch: 5 mm, connection type: Push-in spring connection, conductor connection direction/printed circuit board: 0 °, Clamping hook: - Clamping hook, plug-in system: CLASSIC COMBICON, Locking: without, fixing type: without, packaging type: packed in box

Cables > Cable connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Plug component, nominal current: 10 A, number of positions: 3, pitch: 5 mm, connection method: Push-in spring connection, color: green, contact surface: Tin

logo_rohs.gifLogoLogoLogoLogo

Key Commercial Data

Orderkey1704695
Packing unit1
GTIN4046356733793
Custom tariff number85366990

General

Range of articlesTVFKC 1,5/..-ST
Type of contactFemale connector
Number of positions3
Connection methodPush-in spring connection
Rated voltage (III/3)250 V
Connection in acc. with standardEN-VDE
Nominal current IN10 A
Nominal cross section1.5 mm²

Connection data

Conductor cross section solid min.0.2 mm²
Conductor cross section solid max.1.5 mm²
Conductor cross section flexible min.0.2 mm²
Conductor cross section flexible max.1.5 mm²
Conductor cross section flexible, with ferrule without plastic sleeve min.0.25 mm²
Conductor cross section flexible, with ferrule without plastic sleeve max.1.5 mm²
Conductor cross section flexible, with ferrule with plastic sleeve min.0.25 mm²
Conductor cross section flexible, with ferrule with plastic sleeve max.1.5 mm²
Conductor cross section AWG min.24
Conductor cross section AWG max.16
Minimum AWG according to UL/CUL24
Maximum AWG according to UL/CUL16

Standards and Regulations

Connection in acc. with standardEN-VDE
CUL

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values

eCl@ss

eCl@ss 4.027141109
eCl@ss 4.127141109
eCl@ss 5.027141190
eCl@ss 5.127141190
eCl@ss 6.027261101
eCl@ss 7.027440402
eCl@ss 8.027440309
eCl@ss 9.027440309

ETIM

ETIM 3.0EC001121
ETIM 4.0EC002638
ETIM 5.0EC002638
ETIM 6.0EC002638

UNSPSC

UNSPSC 6.0130211801
UNSPSC 7.090139121432
UNSPSC 1139121432
UNSPSC 12.0139121432
UNSPSC 13.239121409
