View larger
Images are for illustrative purposes only. Please refer to data sheet for details
FK-MPT 0,5/ 4-ST-3,5 BD:04-07 1703188 PHOENIX CONTACT Printed-circuit board connector
FK-MPT 0,5/ 4-ST-3,5 BD:04-07
1703188
PHOENIX CONTACT
50 Pcs.
Printed-circuit board connector
Connector for printed circuit board, nominal section: 0.5 mm², color: green, rated current: 4 A, sizing voltage (III/2): 250 V, surface contacts: Tin, contact type: Connection female, Number of potentials: 4, Number of rows: 1, Number of poles per row: 4, number of connections: 8, article family: FK-MPT 0,5/.. -ST, pitch: 3.5 mm, connection type: Push-in spring connection, conductor/printed circuit board connection address: 0°, pin arrangement: Linear pin arrangement, Stecksystem: COMBICON COMPACT PST 1, Lock: sin, packing type: boxed packaging
Cables > Cable connector
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲General
| Range of articles | FK-MPT 0,5/..-ST |
|---|---|
| Number of positions | 4 |
| Connection method | Push-in spring connection |
| Rated voltage (III/3) | 160 V |
| Connection in acc. with standard | EN-VDE |
| Nominal current IN | 4 A |
| Nominal cross section | 0.5 mm² |
Connection data
| Conductor cross section solid min. | 0.12 mm² |
|---|---|
| Conductor cross section solid max. | 0.5 mm² |
| Conductor cross section AWG min. | 26 |
| Conductor cross section AWG max. | 20 |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
