PHOENIX CONTACT PC 5/ 3-G-7,62 P26 THT R44 PC 5/ 3-G-7,62 P26 THT R44 1753857 PHOENIX CONTACT Printed-circuit board connector View larger
Images are for illustrative purposes only. Please refer to data sheet for details

PC 5/ 3-G-7,62 P26 THT R44 1753857 PHOENIX CONTACT Printed-circuit board connector

PC 5/ 3-G-7,62 P26 THT R44

1753857

PHOENIX CONTACT

65 Pcs.

Printed-circuit board connector Printed circuit board base case, nominal section: 6 mm², color: green, nominal current: 41 A, nominal voltage (III/2): 630 V, contact surface: Tin, contact type: Male, number of rows: 1, number of poles: 3, family of articles: PC 5/.. -G-THR, pitch: 7.62 mm, mounting: THR soldering/wave soldering, conductor connection direction/printed circuit board: 0 °, pin arrangement: Linear pin arrangement, pin length [P]: 2.6 mm, number of solder pins per potential: 3, plug-in system: COMBICON PC 5, Plug-in face orientation: Standard, lock: without, fixing type: without, packaging type: 44 mm wide strap, More user information and design recommendations on Through Hole Reflow technology can be found at: Downloads Printed circuit board base housing, nominal section: 6 mm2, color: green, nominal current: 41 A, nominal voltage (III/2): 630 V, contact surface: Sn, contact connection type: Male, number of rows: 1, number of poles: 3, family of articles: PC 5/..

Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1753857
Packing unit65 pc
Minimum order quantity65 pc
GTIN4046356446471
Weight per Piece (excluding packing)6.800 g
Custom tariff number85366930
Country of originDE (Germany)

Dimensions

Length [ l ]29.25 mm
Width25.66 mm
Pitch7.62 mm
Dimension a15.24 mm
Width [ w ]25.66 mm
Height [ h ]14.29 mm
Height14.29 mm
Length of the solder pin2.6 mm
Pin spacing7.62 mm
Length29.25 mm

General

Range of articlesPC 5/..-G
Rated voltage (III/3)630 V
Connection in acc. with standardEN-VDE
Nominal current IN41 A
Colorgreen
Number of positions3

Standards and Regulations

Connection in acc. with standardEN-VDE
CUL

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values

Classifications


ETIM for 1753857 Connectors (EC002637)
Feature Name Feature Value
Connector model (EF007495) Fixed connector
Contact type (EF001587) Pin
Number of plug-in contact rows (EF006935) 1
Modular spacing contacts (EF007326) 7.62 mm
Modular spacing connections (EF006827) 7.62 mm
Rated current In (EF008250) 41 A
Rated voltage (EF000228) 630 V
Rated surge voltage (EF002993) 6 kV
Over voltage category (EF006785) III
Pollution degree (EF006786) 2
Material of contact surface (EF004020) Tin
Type of electric connection (EF003961) Other
Diameter connection pin (EF006823) 1.3 mm
Length pin (EF006825) 2.6 mm
Housing colour (EF000136) Green
Inflammability class of insulation material according to UL94 (EF002521) V0
Operating temperature (EF002393) -40 °C
Type of fastening (EF002442) Other
Type of banding (EF007011) Other

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
