PHOENIX CONTACT SMSTBA 2,5/ 6-G-5,08 GY SMSTBA 2,5/ 6-G-5,08 GY 1011905 PHOENIX CONTACT Feed-through header SMSTBA 2,5/ 6-G-5,08 GY 1011905 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

SMSTBA 2,5/ 6-G-5,08 GY 1011905 PHOENIX CONTACT Feed-through header SMSTBA 2,5/ 6-G-5,08 GY 1011905

SMSTBA 2,5/ 6-G-5,08 GY

1011905

PHOENIX CONTACT

50 Pcs.

Feed-through header - SMSTBA 2,5/ 6-G-5,08 GY - 1011905 Printed circuit board base housing, nominal section: 2.5 mm², color: gray, nominal current: 12 A, dimensioning voltage (III/2): 320 V, contact surface: Tin, contact type: Male, Number of potentials: 6, Number of rows: 1, Number of poles per row: 6, number of connections: 6, family of articles: SMSTBA 2.5/.. -G, pitch: 5.08 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 3.5 mm, Stecksystem: CLASSIC COMBICON, Locking: without PCB base socket, nominal cross-section: 2.5 mm2, rated current: 12 A, dimensioning voltage (III/2): 320 V, contact surface: Sn, contact connection type: plug, number of potentials: 6, number of rows: 1, number of poles: 6, number of connections: 6, product series: SMSTBA 2.5/.. -G, pitch: 5.08 mm, mounting: Wave soldering, pin layout: Linear pinning, pin length [P]: 3.5 mm, number of solder pins per potential: 1, plug system: COMBICON MSTB 2.5, Insertion pin orientation: Standard, locking: none, fastening type: none

Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

PCB headers, nominal current: 12 A, rated voltage (III/2): 320 V, number of positions: 6, pitch: 5.08 mm, color: gray, contact surface: Tin, mounting: Wave soldering

Key Commercial Data

Orderkey1011905
Packing unit1
GTIN4055626487311
Custom tariff number85366930

Dimensions

Length [ l ]16.5 mm
Width32.48 mm
Pitch5.08 mm
Dimension a25.4 mm
Width [ w ]32.48 mm
Height [ h ]18.3 mm
Height14.8 mm
Length of the solder pin3.5 mm
Pin dimensions1 x 1 mm
Length16.5 mm

General

Range of articlesSMSTBA 2,5/..-G
Colorgray
Number of positions6

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values

Classifications

eCl@ss

eCl@ss 5.127260700
eCl@ss 6.027260700
eCl@ss 7.027440402
eCl@ss 8.027440402
eCl@ss 9.027440402

ETIM

ETIM 5.0EC002637
ETIM 6.0EC002637
ETIM 7.0EC002637
