PHOENIX CONTACT SMC 1,5/ 8-G-3,81 WH SMC 1,5/ 8-G-3,81 WH 1711119 PHOENIX CONTACT Feed-through header View larger
Images are for illustrative purposes only. Please refer to data sheet for details

SMC 1,5/ 8-G-3,81 WH 1711119 PHOENIX CONTACT Feed-through header

SMC 1,5/ 8-G-3,81 WH

1711119

PHOENIX CONTACT

50 Pcs.

Feed-through header Printed circuit board base housing, nominal section: 1.5 mm², color: white, nominal current: 8 A, dimensioning voltage (III/2): 160 V, contact surface: Tin, contact type: Male, Number of potentials: 8, Number of rows: 1, Number of poles per row: 8, number of connections: 8, family of articles: SMC 1.5/.. -G, pitch: 3.81 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 3.4 mm, Stecksystem: MINI COMBICON, Locking:without, packaging type: boxed

Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1711119
Packing unit1
GTIN4055626210315
Custom tariff number85366930

Dimensions

Length [ l ]13.1 mm
Width9.01 mm
Pitch3.81 mm
Dimension a3.81 mm
Width [ w ]9.01 mm
Height [ h ]14.4 mm
Height11 mm
Length of the solder pin3.4 mm
Pin dimensions0.8 x 0.8 mm
Length13.1 mm

General

Range of articlesSMC 1,5/..-G
Insulating material groupI
Rated voltage (III/2)160 V
Nominal current IN8 A
Flammability rating according to UL 94V0
Colorwhite
Number of positions8

Standards and Regulations

Flammability rating according to UL 94V0

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
