View larger
Images are for illustrative purposes only. Please refer to data sheet for details
PC 6-16/ 3-G1-10,16 BK CP1,3 1712498 PHOENIX CONTACT Feed-through header
PC 6-16/ 3-G1-10,16 BK CP1,3
1712498
PHOENIX CONTACT
50 Pcs.
Feed-through header
Printed circuit board base housing, nominal section: 16 mm², color: black, nominal current: 76 A (41 A in combination with PC 6 connector), dimensioning voltage (III/2): 1000 V, contact surface: silver, contact type: Male, Number of potentials: 3, Number of rows: 1, Number of poles per row: 3, number of connections: 3, family of articles: PC 6-16/.. -G1, pitch: 10.16 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 4 mm, Stecksystem: POWER COMBICON 16, Locking: without, packaging type: boxed
Connectors > Printed circuit board connector
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Dimensions
| Length [ l ] | 34 mm |
|---|---|
| Pitch | 10.16 mm |
| Dimension a | 20.32 mm |
| Height [ h ] | 13.4 mm |
| Height | 17.4 mm |
| Length of the solder pin | 4 mm |
| Pin dimensions | 1 x 1.2 mm |
| Pin spacing | 10.16 mm |
| Length | 34 mm |
General
| Range of articles | PC 6-16/..-G1 |
|---|---|
| Insulating material group | I |
| Rated voltage (III/2) | 1000 V |
| Nominal current IN | 76 A (41 A in combination with PC 6 plug) |
| Flammability rating according to UL 94 | V0 |
| Color | black |
| Number of positions | 3 |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
