View larger
Images are for illustrative purposes only. Please refer to data sheet for details
SAC-5P-10,0-800/M12FR VA 1564707 PHOENIX CONTACT Sensor/actuator cable, 5-pole, halogen-free, solder-spark-r..
SAC-5P-10,0-800/M12FR VA
1564707
PHOENIX CONTACT
50 Pcs.
Sensor/actuator cable, 5-pole, halogen-free, solder-spark-resistant, highly flexible, grey RAL 7001, free cable end, to Elbowed Female M12, coding: A, cable length: 10 m, Stainless steel knurling
Sensor/Actuator Cable, Halogen-Free 5-Pole, Weld Spatter Resistant, Highly Flexible, Free Cable End, A Female Angled M12, Encoding: A, Cable Length: 10 m, Stainless Steel Knurling
Sensor/actuator cable, 5-pole halogen-free, suitable for welding applications, ultra-flexible, free end, on M12 angled female connector, keying: A, cable length: 10 m, stainless steel wheel
Automation > Sensor-actuator patch cord
Industrial Field Connectivity (IFC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲| Product Type | Sensor Cable/Actuators |
| Number of poles | 5 |
| Number of cable outlets | 1 |
| Armored | No |
| Keying | A |
| Insulation properties | |
| Surge Category | II |
| Degree of pollution | 3 |
| Flammability class according to UL 94 | HB |
| Seal material | NBR |
| Plug Surface Material | TPU, flame retardant, self-extinguishing |
| Contact material | CuSn |
| Contact surface material | Ni/Au |
| Contact holder material | TPU GF |
| Screwed connection material | Zinc die cast |
| Contact resistance | ≤ 5 mΩ |
| Insulation resistance | ≥ 100 MΩ |
| Rated voltage UN | 60 V |
| Rated Current IN | 4 A |
| Mechanical characteristics | |
| Plugging cycles | ≥ 100 |
| Status display | No |
| Presence of a status display | No |
| Connection 1 | |
| Type | free end |
| Connection 2 | |
| Type | M12 Angled Female Connector |
| Number of poles | 5 |
| Coding Type | A |
| Cable length | 10 m |
| PUR Ultrasoft Grey [800] | |
| Dimensioned drawing |  |
| Note | Due to the robustness of the outer sheath, this cable should only be drawn in 5 cm increments. |
| Sheath Weight | 38 kg/km |
| Style UL AWM | 20549 |
| Number of poles | 5 |
| Armored | No |
| Type | PUR Ultrasoft Grey [800] |
| Conductor structure signal line | 42x 0.10 mm |
| AWG Signal Line | 22 |
| Cable section | 5x 0.34 mm² (Signal Line) |
| Wire diameter with insulation | 1.3 mm ±0.05 mm (Signal Line) |
| Outer diameter of the cable | 5.1 mm ±0.2 mm |
| Outer Sheath, Material | PURE |
| Outer sheath, colour | grey RAL 7001 |
| Conductive material | Bare Cu Cord |
| Filling material | PE |
| Wire Insulating Material | PP |
| Yarn, colour | black, brown, blue, white, grey |
| Total wiring | 5 wires with 2 filling masses in the direction of the core |
| Max. conductor resistance | approx. 53 Ω/km |
| Insulation resistance | ≥ 20 MΩ*km |
| Rated cable voltage | 300 V |
| Test voltage | 2000 V |
| Minimum bending radius, fixed position | 4 x D |
| Minimum bend radius, flexible position | 7.5 x D |
| Minimum bending radius, fixed installation | 21 mm |
| Minimal bending radius, flexible installation | 39 mm |
| Max. bending cycles | 10000000 |
| 15000000 | |
| Torsional stresses | ± 360 °/m |
| Twist cycles | 1000000 |
| Halogen-free | according to DIN VDE 0472 Part 815 |
| Resistance to flame spread | to UL 758/1581 FT2 |
| Oil resistance | according to DIN EN 60811-2-1 |
| Special Resistance | Good resistance to acids, alkaline detergents and solvents |
| silicone-free | |
| Special properties | Cable sheath resistant to welding sparks and friction, recyclable, matte, low adhesion, flame retardant and self-extinguishing |
| free of silicone and cadmium | |
| Free of substances harmful to the application of coatings | |
| Ambient Temperature (Operating) | -40 °C ... 80 °C (cable, fixed installation) |
| -25 °C ... 80 °C (Cable, Flexible Laying) | |
| Environmental conditions | |
| Ingress protection | IP65 |
| IP67 | |
| IP68 | |
| IP69K | |
| Ambient Temperature (Operating) | -25 °C ... 90 °C (male/female connector) |
| -40 °C ... 90 °C (cable, fixed installation) | |
| -30 °C ... 90 °C (Cable, Flexible Lay) | |
