PHOENIX CONTACT SAC-4P-M12MS/4,2-240 SAC-4P-M12MS/4,2-240 1548472 PHOENIX CONTACT Sensor/actuator cable, 4-pole, halogen-free PUR, irradiation cr.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

SAC-4P-M12MS/4,2-240 1548472 PHOENIX CONTACT Sensor/actuator cable, 4-pole, halogen-free PUR, irradiation cr..

SAC-4P-M12MS/4,2-240

1548472

PHOENIX CONTACT

100 Pcs.

Sensor/actuator cable, 4-pole, halogen-free PUR, irradiation cross-linked, orange RAL 2003, Straight M12 connector, coding: A, to free cable end, cable length: 4.2 m Sensor/Actuator Cable, 4-Pole, Halogen-Free PUR, Yellow, M12 Straight Male Connector, Coding: A, To Free Cable End, Cable Length: 4.2 m Sensor/Actuator Cable, Halogen-Free 4-Pole, M12 Straight Connector, Coding: A, Free Cable End, Cable Length: 4.2 m

Automation > Sensor-actuator patch cord
Industrial Field Connectivity (IFC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Technical data
Item Properties
Product TypeSensor/Actuator Cables
Number of poles4
Number of Cable Outlets1
ShieldedNo
Codificationto
Insulation Properties
Surge CategoryIi
Degree of pollution3
Material Data
Flammability class according to UL 94HB
Gasket materialNBR
Grip body materialFire-resistant, self-extinguishing TPU
Contact materialCuSn
Material: Contact SurfaceNi/AU
Contact Support MaterialTPU GF
Screw connection materialZinc die-cast iron, nickel-plated
Electrical Properties
Nominal voltage UN250 V AC
250 V DC
Nominal Current IN4 A
Mechanical Properties
Mechanical data
Plug Cycles≥ 100
Signage
Status IndicationNo
Connectors
Connection 1
ConstructionM12 Straight Connector
Number of poles4
Encoding Typeto
Connection 2
ConstructionFree Cable End
Cable/Line
Cable length4.2 m
Number of poles8
Line Section8x 0.25 mm²
Outer Wrap, MaterialPUR
Outer Wrap, Colororange RAL 2003
Environmental and life-life conditions
Environmental conditions
Protection IndexIP65
IP67
IP68
Ambient Temperature (Service)-25 °C ... 90°C (male/female)
-40 °C ... 80°C (cable, fixed arrangement)
-5 °C ... 80 °C (Cable, movable arrangement)

ETIM for 1548472 Sensors (EC001855)
Feature Name Feature Value
Number of poles (EF001391) 4
Type of electrical connection, field-sided (EF005525) M12
Type of plug-in contact, field sided (EF006269) Male (plug)
Positioning cable feed, field-sided (EF005928) Straight
Type of electrical connection, box-sided (EF005524) Other
Positioning cable feed, box-sided (EF005927) Other
Cable length (EF000536) 4.2 m
Material of cable sheath (EF004136) Other
Halogen free (EF000025) No
Colour cable sheath (EF008249) Other
With LED indication (EF005950) No
Screened (EF000881) No
Cable type (EF000081) Multi-core
Vulcanize (EF004115) No
Material contact body (EF008248) CuSn
Material of contact surface (EF004020) Other
Rated current In (EF008250) 4 A
Rated voltage (EF000228) 250 V
Degree of protection (IP) (EF005474) IP65
