View larger
Images are for illustrative purposes only. Please refer to data sheet for details
SAC-4P-M 8MS/ 1,5-PUR/M 8FS SH 1456349 PHOENIX CONTACT Cable for sensors/actuators, 4-pole, PUR, black RAL 9..
SAC-4P-M 8MS/ 1,5-PUR/M 8FS SH
1456349
PHOENIX CONTACT
25 Pcs.
Cable for sensors/actuators, 4-pole, PUR, black RAL 9005, shielded, male Connector straight M8, to Female connection straight M8, cable length: 1.5 m
Sensor/actuator cable, 4-position, shielded, Plug straight M8, on Socket straight M8, cable length: 1.5 m
Automation > Sensor-actuator patch cord
Industrial Field Connectivity (IFC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Technical data
Product properties
| Product type | Sensor/actuator cable |
| Number of positions | 4 |
| Shielded | yes |
Electrical properties
| Nominal voltage UN | 48 V AC |
| 60 V DC |
Connector
| Connection 1 | |
| Type | Plug straight M8 |
| Number of positions | 4 |
| 4 | |
| Connection 2 | |
| Type | Socket straight M8 |
| Number of positions | 4 |
| 4 | |
Cable/line
| Cable length | 1.5 m |
| PUR halogen-free black [PUR] | |
| Dimensional drawing |  |
| Cable weight | 31 kg/km |
| UL AWM Style | 20549 |
| Number of positions | 4 |
| Shielded | yes |
| Cable type | PUR halogen-free black [PUR] |
| Conductor structure signal line | 32x 0.10 mm |
| AWG signal line | 24 |
| Conductor cross section | 4x 0.25 mm² (Signal line) |
| Wire diameter incl. insulation | 1.17 mm ±0.02 mm (Signal line) |
| External cable diameter | 4.7 mm ±0.15 mm |
| Outer sheath, material | PUR |
| External sheath, color | black-gray RAL 7021 |
| Conductor material | Bare Cu litz wires |
| Material wire insulation | PP |
| Single wire, color | brown, white, blue, black |
| Thickness, insulation | ≥ 0.21 mm (Core insulation) |
| approx. 0.5 mm (Outer cable sheath) | |
| Overall twist | 4 wires, twisted |
| Optical shield covering | 80 % |
| Max. conductor resistance | max. 78 Ω/km (at 20 °C) |
| Insulation resistance | ≥ 100 GΩ*km (at 20 °C) |
| Nominal voltage, cable | ≤ 300 V |
| Test voltage | ≥ 3000 V |
| Smallest bending radius, fixed installation | 24 mm |
| Smallest bending radius, movable installation | 48 mm |
| Max. bending cycles | 10000000 |
| Halogen-free | in accordance with DIN VDE 0472 part 815 |
| Flame resistance | in accordance with UL 758/1581 FT2 |
| DIN EN 60332-2-2 (20 s) | |
| Resistance to oil | in accordance with DIN EN 60811-2-1 |
| Other resistance | Highly resistant to acids, alkaline solutions and solvents |
| hydrolysis and microbe resistant | |
| partly UV-resistant in accordance with DIN EN ISO 4892-2-A | |
| Special properties | Flexible cable conduit capable |
| Silicone-free | |
| Free of substances which would hinder coating with paint or varnish | |
| Ambient temperature (operation) | -40 °C ... 80 °C (cable, fixed installation) |
| -25 °C ... 80 °C (Cable, flexible installation) | |
