PHOENIX CONTACT SAC-3P- 7,0-PUO/A OD SAC-3P- 7,0-PUO/A OD 1426494 PHOENIX CONTACT Sensor/actuator cable SAC-3P- 7,0-PUO/A OD 1426494 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

SAC-3P- 7,0-PUO/A OD 1426494 PHOENIX CONTACT Sensor/actuator cable SAC-3P- 7,0-PUO/A OD 1426494

SAC-3P- 7,0-PUO/A OD

1426494

PHOENIX CONTACT

50 Pcs.

Sensor/actuator cable - SAC-3P- 7,0-PUO/A OD - 1426494 Sensor/actuator cable, 3-position, PUR halogen-free, black RAL 9005, free cable end, on Valve connector A, cable length: 7 m, for outdoor applications

Automation > Sensor-actuator patch cord
Industrial Field Connectivity (IFC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Technical data
Product properties
Product typeSensor/actuator cable with valve connector
Number of positions3
Electrical properties
Nominal voltage UN24 V DC
Connector
Connection 1
Typefree cable end
Connection 2
TypeValve connector A
Cable/line
Cable length7 m
PUR halogen-free black [PUO]
Dimensional drawingbndzhxbtsi.jpg
Number of positions3
Shieldedno
Cable typePUR halogen-free black [PUO]
Conductor structure signal line16x 0.20 mm
AWG signal line20
Conductor cross section3x 0.5 mm²
Wire diameter incl. insulation2 mm ±0.05 mm
External cable diameter5.90 mm ±0.1 mm
Outer sheath, materialPUR
External sheath, colorblack RAL 9005
Conductor materialTin-plated Cu litz wires
Material wire insulationPP
Single wire, colorblack 1, black 2, green/yellow
Overall twist3 wires, twisted
Max. conductor resistance≤ 40.1 Ω/km
Insulation resistance70 GΩ*km
Nominal voltage, cable300 V
Test voltage Core/Core3000 V (Spark test)
Minimum bending radius, fixed installation10 x D
Minimum bending radius, flexible installation15 x D
Smallest bending radius, fixed installation59 mm
Smallest bending radius, movable installation89 mm
Halogen-freein accordance with DIN VDE 0472 part 815
in accordance with EN 50267-2-1
Resistance to oilAccording to DIN EN 50306
According to DIN EN 60811-2-1, 138 h at 100°C
Other resistanceUV resistant
hydrolysis and microbe resistant
Good resistance to aggressive media
Ambient temperature (operation)-40 °C ... 105 °C (cable, fixed installation)
-15 °C ... 105 °C (Cable, flexible installation)
