SAC-2P-MICMS/2,0-542 1553917 PHOENIX CONTACT Sensor/Actuator Cable, 2-Pole, Straight Connector 1/2"-20UNF, t..
SAC-2P-MICMS/2,0-542
1553917
PHOENIX CONTACT
250 Pcs.
Sensor/Actuator Cable, 2-Pole, Straight Connector 1/2"-20UNF, to Free Cable End, Cable Length: 2 m
Cable for sensors/actuators
Sensor/actuator cable, 2-position, Plug straight 1/2"-20UNF, on free cable end, cable length: 2 m
Automation > Sensor-actuator patch cord
Industrial Field Connectivity (IFC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Technical data
Product properties
| Number of positions | 2 |
| No. of cable outlets | 1 |
| Shielded | no |
Material specifications
| Seal material | NBR |
| Material of grip body | TPU, hardly inflammable, self-extinguishing |
| Contact material | CuZn |
| Contact surface material | Ni/Au |
| Contact carrier material | TPU GF |
| Material for screw connection | Brass, nickel-plated |
Connector
| Connection 1 | |
| Type | Plug straight 1/2"-20UNF |
| Number of positions | 2 |
| Connection 2 | |
| Type | free cable end |
Cable/line
| Cable length | 2 m |
| PVC yellow 105 °C [542] | |
| Dimensional drawing |  |
| Shielded | no |
| UL AWM Style | 2517 (105 °C / 300 V) |
| Cable weight | 32 kg/km |
| Cable type | PVC yellow 105 °C |
| Short symbol | LiYY |
| Cable type (abbreviation) | 542 |
| External cable diameter | 4.9 mm ±0.15 mm |
| Outer sheath, material | PVC |
| External sheath, color | yellow |
| Thickness, outer sheath | ≥ 0.76 mm |
| Conductor material | Bare Cu litz wires |
| Conductor structure signal line | 42x 0.10 mm |
| AWG signal line | 22 |
| Conductor cross section | 2x 0.34 mm² |
| Material wire insulation | PVC |
| Thickness, insulation | ≥ 0.38 mm (Core insulation) |
| Wire diameter incl. insulation | 1.55 mm ±0.05 mm |
| Single wire, color | brown, blue |
| Overall twist | 2 wires, twisted |
| Nominal voltage, cable | ≤ 300 V |
| Test voltage, cable | ≥ 3000 V |
| Cable resistance | 58 Ω/m (at 20 °C) |
| Cable insulation resistance | ≥ 100 MΩ*km (at 20 °C) |
| Flame resistance | According to DIN EN 60332-1-2 |
| Ambient temperature (operation) | -5 °C ... 105 °C (Cable, flexible installation) |
| -25 °C ... 105 °C (Cable) | |
Environmental and real-life conditions
| Ambient conditions | |
| Ambient temperature (operation) | -25 °C ... 90 °C (Plug / socket) |
| -25 °C ... 80 °C (cable, fixed installation) | |
| -5 °C ... 80 °C (Cable, flexible installation) | |
| Feature Name | Feature Value |
|---|---|
| Number of poles (EF001391) | 2 |
| Type of electrical connection, field-sided (EF005525) | Other |
| Type of plug-in contact, field sided (EF006269) | Male (plug) |
| Positioning cable feed, field-sided (EF005928) | Straight |
| Type of electrical connection, box-sided (EF005524) | Other |
| Positioning cable feed, box-sided (EF005927) | Other |
| Cable length (EF000536) | 2 m |
| Material of cable sheath (EF004136) | Polyvinyl chloride (PVC) |
| Halogen free (EF000025) | No |
| Colour cable sheath (EF008249) | Yellow |
| With LED indication (EF005950) | No |
| Screened (EF000881) | No |
| Cable type (EF000081) | Multi-core |
| Vulcanize (EF004115) | No |
| Material contact body (EF008248) | CuZn |
| Material of contact surface (EF004020) | Other |
| Permitted cable outer temperature after assembling without vibration (EF001686) | -25 °C |
| Permitted cable outer temperature during assembling/handling (EF001685) | -5 °C |
