View larger
Images are for illustrative purposes only. Please refer to data sheet for details
SAC-2P-M8MS/0,5-PUR/BI-1LZ 180 1552064 PHOENIX CONTACT Cable, Straight M8 connector, coding: A, a BI valve c..
SAC-2P-M8MS/0,5-PUR/BI-1LZ 180
1552064
PHOENIX CONTACT
100 Pcs.
Cable, Straight M8 connector, coding: A, a BI valve connectors (11 mm), with 1 LED, Circuit: Diode Z, cable length: 0.5 m
Cable
Cable, PUR, M8 Straight Connector, Coding: A, A BI Valve Connectors (11 mm), with 1 LED, Z Diode Connected, Cable Length: 0.5 m
Automation > Sensor-actuator patch cord
Industrial Field Connectivity (IFC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Technical data
Material Data
| Outer Wrap, Material | PUR |
Connectors
| Connection 1 | |
| Construction | M8 Straight Connector |
| Encoding Type | to |
| Connection 2 | |
| Construction | BI Valve Connectors (11 mm) |
Cable/Line
| Cable length | 0.5 m |
| Halogen-free PUR Black [PUR] | |
| Dimension Scheme |  |
| Shielded | No |
| UL AWM Style | 20549 / 10152 (80°C/300 V) |
| Cable Weight | 25 kg/km |
| Cable type | Halogen-free PUR black |
| Abbreviation | Li9Y11Y |
| Cable Type (abbreviation) | PUR |
| Cable Outer Diameter | 4.25 mm ±0.15 mm |
| Outer Wrap, Material | PUR |
| Outer Wrap, Color | greyish black RAL 7021 |
| Wall Thickness Outer Wrap | ≥ 0.38 mm |
| Conductive Material | Naked Cu Conductor |
| Conductor Construction Signal Cable | 28x 0.15 mm |
| AWG Signal Line | 20 |
| Line Section | 2x 0.5 mm² |
| Material: Conductor Insulation | PP |
| Conductor diameter incl. insulation | 1.46 mm ±0.05 mm |
| Single Driver, Color | brown, blue |
| Nominal Voltage Cable | ≤ 300 V AC |
| Test Voltage Cable | ≥ 3000 V AC (Spark Test) |
| Line Resistance | ≤ 39 Ω/km (at 20 °C) |
| Line Insulation Resistance | ≥ 1 GΩ*km (at 20 °C) |
| Minimum bending radius, fixed | 5 x D |
| Minimum bending radius, flexibly positioned | 10 x D |
| Number of bending cycles | 4000000 |
| Bend radius, drag chain insert | 10 x D |
| Advance path | 10 m |
| Feed rate | 3 m/s |
| Acceleration | 10 m/s² |
| Absence of halogens | according to DIN VDE 0472 part 815 |
| according to DIN EN 50267-2-1 | |
| Oil Resistance | according to DIN EN 60811-2-1, 168 h at 100 °C |
| Flame Resistance | according to UL 758/1581 (horizontal) |
| according to UL 758/1581 FT2 | |
| Other resistances | resistant to hydrolysis and microbes |
| UV-resistant conditional according to DIN EN ISO 4892-2-A | |
| Sea Water Resistant | |
| Non-adherent | |
| Abrasion resistant | |
| Special Features | flexible |
| suitable for energy chains | |
| Ambient Temperature (Service) | -25 °C ... 80 °C (Cable, movable arrangement) |
| -40 °C ... 80°C (cable, fixed arrangement) | |
| Feature Name | Feature Value |
|---|---|
| Type of electrical connection, field-sided (EF005525) | M8 |
| Type of plug-in contact, field sided (EF006269) | Male (plug) |
| Positioning cable feed, field-sided (EF005928) | Straight |
| Type of electrical connection, box-sided (EF005524) | M8 |
| Type of plug-in contact, box-sided (EF008386) | Male (plug) |
| Positioning cable feed, box-sided (EF005927) | Straight |
| Cable length (EF000536) | 0.5 m |
| Material of cable sheath (EF004136) | Other |
| Halogen free (EF000025) | Yes |
| Colour cable sheath (EF008249) | Other |
| With LED indication (EF005950) | No |
| Screened (EF000881) | No |
| Vulcanize (EF004115) | No |
| Permitted cable outer temperature after assembling without vibration (EF001686) | -40 °C |
| Permitted cable outer temperature during assembling/handling (EF001685) | -25 °C |
