View larger
Images are for illustrative purposes only. Please refer to data sheet for details
FKIC 2,5/ 7-ST-5,08 BD:L3-DA- 1716023 PHOENIX CONTACT Printed-circuit board connector
FKIC 2,5/ 7-ST-5,08 BD:L3-DA-
1716023
PHOENIX CONTACT
50 Pcs.
Printed-circuit board connector
Printed circuit board connector, nominal section: 2.5 mm2, nominal current: 12 A, nominal voltage (III/2): 320 V, contact surface: Sn, contact connection type: Male, number of potentials: 7, number of rows: 1, number of poles: 7, number of connections: 7, family of articles: FKIC 2.5/.. -ST, pitch: 5.08 mm, connection type: Push-in spring connection, conductor connection direction/printed circuit board: 0 °, clamping hook: - without clamping hook, plug-in system: COMBICON MSTB 2.5, locking: without, fixing type: without, packaging type: boxed
Cables > Cable connector
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲General
| Range of articles | FKIC 2,5/..-ST |
|---|---|
| Number of positions | 7 |
| Connection method | Push-in spring connection |
| Insulating material group | I |
| Rated voltage (III/2) | 320 V |
| Nominal current IN | 12 A |
| Nominal cross section | 2.5 mm² |
| Flammability rating according to UL 94 | V0 |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
