View larger
Images are for illustrative purposes only. Please refer to data sheet for details
PT 2,5/ 6-5,0-H 3PA 1711216 PHOENIX CONTACT Screw compact terminal block
PT 2,5/ 6-5,0-H 3PA
1711216
PHOENIX CONTACT
100 Pcs.
Screw compact terminal block
Terminal block for printed circuit board, nominal current: 32 A, nominal voltage (III/2): 400 V, nominal section: 2.5 mm², number of potentials: 3, number of rows: 1, number of poles per row: 6, family of articles: PT 2.5/.. -H, pitch: 5 mm, connection type: Screw connection with wire protection bracket, mounting: Wave soldering, conductor connection direction/printed circuit board: 0 °, color: green, Pin arrangement: Linear pin arrangement, Pin length [P]: 4.1 mm, number of solder pins per potential: 1, packaging type: boxed. In case of using ferrules, 250 V is only reached in combination with the surge category / the dirt grade II/2.
Connectors > Printed circuit board terminal
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Dimensions
| Length [ l ] | 9 mm |
|---|---|
| Pitch | 5 mm |
| Dimension a | 5 mm |
| Height | 13.5 mm |
| Height [ h ] | 13.5 mm |
| Solder pin [P] | 4.1 mm |
| Pin spacing | 5 mm |
| Hole diameter | 1.3 mm |
General
| Range of articles | PT 2,5/..-H |
|---|---|
| Insulating material group | I |
| Rated voltage (III/2) | 400 V |
| Nominal current IN | 32 A |
| Nominal cross section | 2.5 mm² |
| Solder pin surface | |
| Flammability rating according to UL 94 | V0 |
| Number of positions | 6 |
| Screw thread | M3 |
Environmental Product Compliance
| China RoHS | Environmentally Friendly Use Period = 50 |
|---|---|
| For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” |
Classifications
| Feature Name | Feature Value |
|---|---|
| Number of poles (EF001391) | 6 |
| Inflammability class of insulation material according to UL94 (EF002521) | V0 |
