> PHOENIX CONTACT > PCB Connectors (PCC) > 1715216
PHOENIX CONTACT QC 1,5/ 2-ST BS:N,L QC 1,5/ 2-ST BS:N,L 1715216 PHOENIX CONTACT Plug View larger
Images are for illustrative purposes only. Please refer to data sheet for details

QC 1,5/ 2-ST BS:N,L 1715216 PHOENIX CONTACT Plug

QC 1,5/ 2-ST BS:N,L

1715216

PHOENIX CONTACT

50 Pcs.

Plug Connector for printed circuit board, color: green, contact surface: Tin, Number of poles per row: 2, family of items: QC 1.5/.. -ST, Pitch: 5mm, Packing Type: Boxed Packed PCB connector, number of positions: 2, product range: QC 1,5/..-ST, pitch: 5 mm, type of packaging: packed in cardboard

Cables > Cable connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Technical data
Product properties
Product typePCB connector
Product familyQC 1,5/..-ST
Number of positions2
Pitch5 mm
Data management status
Article revision00
Electrical properties
Rated voltage (III/2)630 V
Material specifications
Flammability rating according to UL 94V0
Insulating material groupI
Contact surfaceTin Sn
Dimensions
Width11.4 mm
Installed height19.6 mm
Height19.6 mm
Length36.9 mm
Pitch5 mm
Packaging specifications
Type of packagingpacked in cardboard

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
