View larger
Images are for illustrative purposes only. Please refer to data sheet for details
QC 1/ 2-ST-5,08 BD:-,+ 1712270 PHOENIX CONTACT Printed-circuit board connector
QC 1/ 2-ST-5,08 BD:-,+
1712270
PHOENIX CONTACT
50 Pcs.
Printed-circuit board connector
Cables > Cable connector
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Key Commercial Data
| Orderkey | 1712270 |
|---|---|
| Packing unit | 50 pc |
| Minimum order quantity | 1000 pc |
| Note | Made to Order (non-returnable) |
| GTIN | 4046356084376 |
| Weight per Piece (excluding packing) | 3.950 g |
| Custom tariff number | 85366990 |
| Country of origin | PL (Poland) |
General
| Range of articles | QC 1/..-ST |
|---|---|
| Number of positions | 2 |
| Connection method | Displacement connection |
| Rated voltage (III/3) | 500 V |
| Connection in acc. with standard | EN-VDE |
| Nominal current IN | 10 A |
| Nominal cross section | 1 mm² |
Connection data
| Conductor cross section flexible min. | 0.5 mm² |
|---|---|
| Conductor cross section flexible max. | 1 mm² |
| Conductor cross section AWG min. | 20 |
| Conductor cross section AWG max. | 18 |
| Minimum AWG according to UL/CUL | 22 |
| Maximum AWG according to UL/CUL | 18 |
| Wire diameter incl. insulation | 2.5 mm |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
