View larger
Images are for illustrative purposes only. Please refer to data sheet for details
PTSA 1,5/ 2-3,5-Z MCBU/BK 1716779 PHOENIX CONTACT PCB terminal block
PTSA 1,5/ 2-3,5-Z MCBU/BK
1716779
PHOENIX CONTACT
420 Pcs.
PCB terminal block
Connectors > Printed circuit board terminal
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Dimensions
| Length [ l ] | 12 mm |
|---|---|
| Pitch | 3.5 mm |
| Dimension a | 3.5 mm |
| Width [ w ] | 8.5 mm |
| Height | 13.1 mm |
| Height [ h ] | 16.7 mm |
| Solder pin [P] | 3.6 mm |
| Pin spacing | 3.5 mm |
| Hole diameter | 1 mm |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
