PHOENIX CONTACT PTSA 0,5/ 8-2,5-F MCOG-BU PTSA 0,5/ 8-2,5-F MCOG-BU 1716756 PHOENIX CONTACT PCB terminal block, nominal current: 2 A, rated voltage (I.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

PTSA 0,5/ 8-2,5-F MCOG-BU 1716756 PHOENIX CONTACT PCB terminal block, nominal current: 2 A, rated voltage (I..

PTSA 0,5/ 8-2,5-F MCOG-BU

1716756

PHOENIX CONTACT

50 Pcs.

PCB terminal block, nominal current: 2 A, rated voltage (III/2): 250 V, nominal cross section: 0.5 mm², pitch: 2.5 mm, number of positions: 8, connection method: Push-in spring connection, mounting: Wave soldering, conductor/PCB connection direction: 45 °, color: multi-color, Pin layout: Linear pinning, Solder pin [P]: 3.6 mm Terminal block for printed circuit board, rated current: 2 A, dimensioning voltage (III/2): 250 V, nominal cross-section: 0.5 mm², Number of potentials: 8, Number of rows: 1, Number of poles per row: 8, article family: PTSA 0.5, pitch: 2.5 mm, connection type: Push-in spring connection, mounting: Wave soldering, conductor connection direction/printed circuit board: 45°, color: multicolor, Pin arrangement: Linear pin arrangement, Pin length [P]: 3.6 mm, packaging type: boxed

Connectors > Printed circuit board terminal
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1716756
Packing unit1
GTIN4055626698564
Custom tariff number85369010

Drawings

Diagram

Diagram
Derating diagram for 5 pins;reduction factor=1

Back to top

Item properties

Brief article descriptionPCB terminal block
Range of articlesPTSA 0,5
Pitch2.5 mm
Number of positions8
Connection methodPush-in spring connection
Mounting typeWave soldering
Pin layoutLinear pinning
Number of levels1
Number of connections8
Number of potentials8
Back to top

Electrical parameters

Nom. voltage250 V
Back to top

Connection capacity

Connection methodPush-in spring connection
pluggableno
Conductor cross section solid0.14 mm² ... 0.5 mm²
Conductor cross section flexible0.2 mm² ... 0.5 mm²
Conductor cross section AWG / kcmil24 ... 20
Stripping length9 mm
Back to top

Material data - contact

NoteWEEE/RoHS-compliant, free of whiskers according to IEC 60068-2-82/JEDEC JESD 201
Contact materialCu alloy
Surface characteristicshot-dip tin-plated
Metal surface terminal point (top layer)Tin (4 - 8 µm Sn)
Metal surface soldering area (top layer)Tin (4 - 8 µm Sn)
Back to top

Material data - housing

Insulating materialPA
Insulating material groupI
CTI according to IEC 60112600
Flammability rating according to UL 94V0
Glow wire flammability index GWFI according to EN 60695-2-12850
Glow wire ignition temperature GWIT according to EN 60695-2-13775
Temperature for the ball pressure test according to EN 60695-10-2125 °C
Back to top

Dimensions for the product

Dimensional drawing
CaptionThe figure shows the 5-pos. version
Length [ l ]12 mm
Width [ w ]21.5 mm
Height [ h ]16.7 mm
Pitch2.5 mm
Height (without solder pin)13.1 mm
Solder pin [P]3.6 mm
Pin spacing2.5 mm
Pin dimensions0.4 x 0.75 mm
Dimension a17.5 mm
Back to top

Dimensions for PCB design

Hole diameter1 mm
Pin spacing2.5 mm
Back to top

Packaging information

Type of packagingpacked in cardboard
Pieces per package50
Denomination packing unitsPcs.
Back to top

Ambient conditions

Ambient temperature (storage/transport)-40 °C ... 70 °C
Ambient temperature (assembly)-5 °C ... 55 °C
Ambient temperature (operation)-40 °C ... 85 °C
Back to top

Termination and connection method

Connection testIEC 60998-2-2:1991-10
Test resultTest passed
Test for conductor damage and slackeningIEC 60998-2-2:1991-10
Test passed
Back to top

Pull-out test

Pull-out testIEC 60998-2-2:1991-10
Test passed
Conductor cross section / conductor type / tensile force0.14 mm² / solid / > 7 N
0.2 mm² / flexible / > 10 N
0.5 mm² / solid / > 30 N
0.5 mm² / flexible / > 30 N
Back to top

Electrical tests

Rated current2 A
Conductor cross section0.5 mm²
Rated voltage (III/2)250 V
Rated surge voltage (III/2)2.5 kV
Back to top

Air clearances and creepage distances

Clearances and creepage distancesIEC 60947-1:2007-06 + A1:2010-12 + A2:2014-09
SpecificationIEC 60947-1:2007-06 + A1:2010-12 + A2:2014-09
Rated insulation voltage (III/3)63 V
Rated insulation voltage (III/2)250 V
Rated insulation voltage (II/2)320 V
Rated surge voltage (III/3)2.5 kV
Rated surge voltage (III/2)2.5 kV
Rated surge voltage (II/2)2.5 kV
Minimum clearance - inhomogeneous field (III/3)1.5 mm
Minimum clearance - inhomogeneous field (III/2)1.5 mm
Minimum clearance - inhomogeneous field (II/2)1.5 mm
Minimum creepage distance value (III/3)1.6 mm
Minimum creepage distance value (III/2)1.5 mm
Minimum creepage distance value (II/2)1.6 mm
Back to top

Vibration test

SpecificationIEC 60068-2-6:1995-03
ResultTest passed
Frequency10 - 150 - 10 Hz
Sweep speed1 octave/min
Amplitude0.35 mm (10 - 60.1 Hz)
Acceleration5 g (60.1 - 150 Hz)
Test duration per axis2.5 h
Back to top

Resistance to ageing, humidity and penetration of solids

Dry heat168 h/100°C
Humid heat48 h/30 °C/92 %
Back to top

Classifications

eCl@ss

eCl@ss 5.127261100
eCl@ss 6.027261100
eCl@ss 7.027440401
eCl@ss 8.027440401
eCl@ss 9.027440401
Back to top

ETIM

ETIM 5.0EC002643
ETIM 6.0EC002643
ETIM 7.0EC002643
