PHOENIX CONTACT PTSA 0,5/ 4-2,5-F BD:1-4 PTSA 0,5/ 4-2,5-F BD:1-4 1737491 PHOENIX CONTACT PCB terminal block View larger
Images are for illustrative purposes only. Please refer to data sheet for details

PTSA 0,5/ 4-2,5-F BD:1-4 1737491 PHOENIX CONTACT PCB terminal block

PTSA 0,5/ 4-2,5-F BD:1-4

1737491

PHOENIX CONTACT

250 Pcs.

PCB terminal block Terminal block for printed circuit board, nominal current: 2 A, dimensioning voltage (III/2): 250 V, nominal cross-section: 0.5 mm², Number of potentials: 4, Number of rows: 1, Number of poles per row: 4, article family: PTSA 0.5, pitch: 2.5 mm, connection type: Push-in spring connection, mounting: Wave soldering, conductor connection direction/printed circuit board: 45 °, color: green, Pin arrangement: Linear pin arrangement, Pin length [P]: 3.6 mm, packaging type: boxed packaging. Welding pins in the anterior area, one row

Connectors > Printed circuit board terminal
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1737491
Packing unit250 pc
Minimum order quantity250 pc
NoteMade to Order (non-returnable)
GTIN4046356183796
Weight per Piece (excluding packing)1.550 g
Custom tariff number85369010
Country of originPL (Poland)

Dimensions

Length [ l ]12 mm
Pitch2.5 mm
Dimension a7.5 mm
Width [ w ]11.5 mm
Height13.1 mm
Height [ h ]16.7 mm
Solder pin [P]3.6 mm
Pin spacing2.5 mm
Hole diameter1 mm

General

Range of articlesPTSA 0,5
Rated surge voltage (III/3)2.5 kV
Rated surge voltage (III/2)2.5 kV
Rated surge voltage (II/2)2.5 kV
Rated voltage (III/3)63 V
Rated voltage (III/2)250 V
Rated voltage (II/2)250 V
Connection in acc. with standardEN-VDE
Nominal current IN2 A
Nominal cross section0.5 mm²
Solder pin surface
Stripping length9 mm
Number of positions4

Connection data

Conductor cross section AWG min.24
Conductor cross section AWG max.20

Standards and Regulations

Connection in acc. with standardEN-VDE
CUL

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
