PHOENIX CONTACT PT 1,5/ 4-PH-5,0 CLIP BD:AB-+ PT 1,5/ 4-PH-5,0 CLIP BD:AB-+ 1706318 PHOENIX CONTACT Plug-in part, rated current: 10 A, number of poles: 4,.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

PT 1,5/ 4-PH-5,0 CLIP BD:AB-+ 1706318 PHOENIX CONTACT Plug-in part, rated current: 10 A, number of poles: 4,..

PT 1,5/ 4-PH-5,0 CLIP BD:AB-+

1706318

PHOENIX CONTACT

250 Pcs.

Plug-in part, rated current: 10 A, number of poles: 4, pitch: 5 mm, connection type: Screw connection with traction capsule, color: green, contact surface: Tin Connector for printed circuit board, nominal section: 1.5 mm², color: green, nominal current: 10 A, nominal voltage (III/2): 400 V, contact surface: Tin, contact type: Female, number of potentials: 4, number of rows: 1, number of poles: 4, number of connections: 4, family of articles: PT 1.5/.. -PH CLIP, pitch: 5 mm, connection type: Screw connection with traction capsule, screw clamping method: H1L Philipps-Recess with longitudinal groove, conductor connection direction/printed circuit board: 0 °, plug-in system: COMBICON PST 1.3, lock: without, fixing type: without, packaging type: boxed

Cables > Cable connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Plug component, nominal current: 10 A, number of positions: 4, pitch: 5 mm, connection method: Screw connection with tension sleeve, color: green, contact surface: Tin

General

Range of articlesPT 1,5/..-PH CLIP
Type of contactFemale connector
Number of positions4
Connection methodScrew connection with tension sleeve
Rated voltage (III/3)250 V
Connection in acc. with standardEN-VDE
Nominal current IN10 A
Nominal cross section1.5 mm²

Connection data

Conductor cross section solid min.0.2 mm²
Conductor cross section solid max.1.5 mm²
Conductor cross section flexible min.0.2 mm²
Conductor cross section flexible max.1.5 mm²
Conductor cross section flexible, with ferrule without plastic sleeve min.0.25 mm²
Conductor cross section flexible, with ferrule without plastic sleeve max.1 mm²
Conductor cross section flexible, with ferrule with plastic sleeve min.0.25 mm²
Conductor cross section flexible, with ferrule with plastic sleeve max.1 mm²
Conductor cross section AWG min.26
Conductor cross section AWG max.14
2 conductors with same cross section, stranded, ferrules without plastic sleeve, max.0.5 mm²
Minimum AWG according to UL/CUL28
Maximum AWG according to UL/CUL14

Standards and Regulations

Connection in acc. with standardEN-VDE
CUL

Environmental Product Compliance

China RoHSEnvironmentally Friendly Use Period = 50
For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration”

eCl@ss

eCl@ss 4.027141111
eCl@ss 4.127141109
eCl@ss 5.027141190
eCl@ss 5.127141190
eCl@ss 6.027261101
eCl@ss 7.027440401
eCl@ss 8.027440309
eCl@ss 9.027440309

ETIM

ETIM 3.0EC001121
ETIM 4.0EC002638
ETIM 5.0EC002638
ETIM 6.0EC002638

UNSPSC

UNSPSC 6.0130211801
UNSPSC 7.090139121432
UNSPSC 1134131203
UNSPSC 12.0139121432
UNSPSC 13.239121409
