View larger
Images are for illustrative purposes only. Please refer to data sheet for details
SD FLASH 512MB 2988146 PHOENIX CONTACT Program and configuration memory, plug-in, 512 Mbyte.
SD FLASH 512MB
2988146
PHOENIX CONTACT
1 Pcs.
Program and configuration memory, plug-in, 512 Mbyte.
Automation > PLC memory card
Control Systems (CST)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Technical data
Notes
| Note on application | |
| Note on application | Only for industrial use |
Product properties
| Product type | Storage medium |
| Application | Program/configuration memory |
| Mounting position | vertical |
Electrical properties
| Maximum power dissipation for nominal condition | 0.165 W |
| Supply | |
| Supply voltage | 3.3 V DC |
| Supply voltage range | 2.7 V DC ... 3.6 V DC |
| Typical current consumption | typ. 50 mA |
Material specifications
| Housing material | Plastic |
Environmental and real-life conditions
| Ambient conditions | |
| Ambient temperature (operation) | -40 °C ... 85 °C |
Mounting
| Mounting position | vertical |
| Feature Name | Feature Value |
|---|---|
| Type of memory (EF002996) | Other |
| Memory size (EF002997) | 524288 kByte |
