PHOENIX CONTACT SD FLASH 512MB APPLIC A SD FLASH 512MB APPLIC A 2701799 PHOENIX CONTACT Program and configuration memory, plug-in, 512 MB with licen.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

SD FLASH 512MB APPLIC A 2701799 PHOENIX CONTACT Program and configuration memory, plug-in, 512 MB with licen..

SD FLASH 512MB APPLIC A

2701799

PHOENIX CONTACT

1 Pcs.

Program and configuration memory, plug-in, 512 MB with license key for functional block libraries, e.g., for: SNMP, SQL, wireless, motion functions, etc. Program and configuration memory for expansion of internal flash memory, pluggable, 512 MByte with license key for function block libraries. You can see the function blocks that require a license in the documentation.

Automation > PLC memory card
Control Systems (CST)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Product description

Program and configuration memory for storing the application program and other files in the file system of the PLC, with license key for the function block libraries.

Individual function blocks from Phoenix Contact, such as those from the SQL and SNMP library or Resy+, are licensed, which means that a fee is charged for each controller on which licensed blocks are to be used. The blocks check the license stored on the controller during runtime and enable themselves or run for a limited time in demo mode.

Examples:

• Basic control functions for PID controllers with delay time constant in the D component

• Data transfer between the controller and SQL database with event-driven access to tables by means of SQL communication and Data Manipulation Language (DML)

• IT library for sending e-mails with the SMTP function, with DHCP client, DNS, and an FTP client function

• Secure, event-oriented, and inexpensive monitoring of all distributed plants via Ethernet as well as via serial interfaces

Please observe the specified performance data of your controller(s) and check that it/they are suitable for your application.

For users who do not use the function block libraries, the program and configuration memory is also available without a license as an option.


ETIM for 2701799 PLC's (EC000192)
Feature Name Feature Value
Type of memory (EF002996) Other
Memory size (EF002997) 524288 kByte
