PHOENIX CONTACT QC 0,5/ 2-ST-3,81 QC 0,5/ 2-ST-3,81 1897393 PHOENIX CONTACT Printed-circuit board connector View larger
Images are for illustrative purposes only. Please refer to data sheet for details

QC 0,5/ 2-ST-3,81 1897393 PHOENIX CONTACT Printed-circuit board connector

QC 0,5/ 2-ST-3,81

1897393

PHOENIX CONTACT

50 Pcs.

Printed-circuit board connector Connector for printed circuit board, nominal section: 0.5 mm², color: green, nominal current: 6 A, nominal voltage (III/2): 200 V, contact surface: Tin, contact type: Female, number of potentials: 2, number of rows: 1, number of poles: 2, number of connections: 2, family of articles: QC 0.5/.. -ST, pitch: 3.81 mm, connection type: Offset connection, conductor/printed circuit board connection direction: 0°, plug-in system: COMBICON MC 1.5, lock: without, fixing type: without, packaging type: boxed

Cables > Cable connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1897393
Packing unit50 pc
Minimum order quantity50 pc
Catalog pagePage 204 (C-1-2013)
GTIN4017918164898
Weight per Piece (excluding packing)2.120 g
Custom tariff number85366990
Country of originCN (China)

Dimensions

Length [ l ]22.3 mm
Width [ w ]4.6 mm
Height [ h ]12.4 mm
Pitch3.81 mm
Dimension a3.81 mm

General

Range of articlesQC 0,5/..-ST
Number of positions2
Connection methodDisplacement connection
Insulating material groupI
Rated surge voltage (III/3)4 kV
Rated surge voltage (III/2)4 kV
Rated surge voltage (II/2)4 kV
Rated voltage (III/3)200 V
Rated voltage (III/2)200 V
Rated voltage (II/2)400 V
Connection in acc. with standardEN-VDE
Nominal current IN6 A
Nominal cross section0.5 mm²
Maximum load current6 A (with 0.5 mm² conductor cross section)
Insulating materialPA
Flammability rating according to UL 94V0

Connection data

Conductor cross section flexible min.0.34 mm²
Conductor cross section flexible max.0.5 mm²
Conductor cross section AWG min.22
Conductor cross section AWG max.20
Minimum AWG according to UL/CUL24
Maximum AWG according to UL/CUL20
Wire diameter incl. insulation2.2 mm

Standards and Regulations

Connection in acc. with standardEN-VDE
CUL
Flammability rating according to UL 94V0

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
