PHOENIX CONTACT FK-MPT 0,5/ 6-ST-3,5 FK-MPT 0,5/ 6-ST-3,5 1913963 PHOENIX CONTACT PCB terminal block View larger
Images are for illustrative purposes only. Please refer to data sheet for details

FK-MPT 0,5/ 6-ST-3,5 1913963 PHOENIX CONTACT PCB terminal block

FK-MPT 0,5/ 6-ST-3,5

1913963

PHOENIX CONTACT

50 Pcs.

PCB terminal block Connector for printed circuit board, nominal section: 0.5 mm², color: green, nominal current: 4 A, nominal voltage (III/2): 250 V, contact surface: Tin, contact type: Female, number of potentials: 6, number of rows: 1, number of poles: 6, number of connections: 12, article family: FK-MPT 0.5/.. -ST, pitch: 3.5mm, connection type: Push-in spring connection, driver/printed circuit board connection direction: 0°, plug-in system: COMBICON PST 1.0, lock: without, fixing type: without, packaging type: boxed

Cables > Cable connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1913963
Packing unit50 pc
Minimum order quantity50 pc
NoteMade to Order (non-returnable)
Catalog pagePage 403 (C-1-2013)
GTIN4017918176877
Weight per Piece (excluding packing)1.970 g
Custom tariff number85366990
Country of originDE (Germany)

Dimensions

Length [ l ]9.5 mm
Width [ w ]21.5 mm
Height [ h ]8.5 mm
Pitch3.5 mm
Dimension a17.5 mm

General

Range of articlesFK-MPT 0,5/..-ST
Number of positions6
Connection methodPush-in spring connection
Insulating material groupIIIa
Rated surge voltage (III/3)2.5 kV
Rated surge voltage (III/2)2.5 kV
Rated surge voltage (II/2)2.5 kV
Rated voltage (III/3)160 V
Rated voltage (III/2)250 V
Rated voltage (II/2)250 V
Connection in acc. with standardEN-VDE
Nominal current IN4 A
Nominal cross section0.5 mm²
Maximum load current4 A (with 0.5 mm² conductor cross section)
Insulating materialPBT
Flammability rating according to UL 94V0
Stripping length6.5 mm

Connection data

Conductor cross section solid min.0.12 mm²
Conductor cross section solid max.0.5 mm²
Conductor cross section AWG min.26
Conductor cross section AWG max.20
Minimum AWG according to UL/CUL28
Maximum AWG according to UL/CUL20

Standards and Regulations

Connection in acc. with standardEN-VDE
CUL
Flammability rating according to UL 94V0

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values

Classifications


ETIM for 1913963 Connectors (EC002638)
Feature Name Feature Value
Type of connection (EF000064) Other
Contact type (EF001587) Bus
Number of poles (EF001391) 12
Number of plug-in contact rows (EF006935) 1
Modular spacing contacts (EF007326) 3.5 mm
Modular spacing connections (EF006827) 3.5 mm
Angle contact/conductor connection (EF007546) Other
Rated current In (EF008250) 4 A
Rated voltage (EF000228) 250 V
Rated surge voltage (EF002993) 2.5 kV
Over voltage category (EF006785) III
Pollution degree (EF006786) 2
Connectable conductor cross section solid-core (EF007337) 0.12 mm²
Type of electric connection (EF003961) Spring clamp connection
Connectable cable type (EF006816) Tubular cable
Material of contact surface (EF004020) Tin
Material contact (EF007544) Copper
Material insulation body (EF007543) Other
Housing material (EF001596) Other
Housing colour (EF000136) Green
Inflammability class of insulation material according to UL94 (EF002521) V0
Operating temperature (EF002393) -40 °C
