PHOENIX CONTACT FK-MPT 0,5/14-ST-3,5 FK-MPT 0,5/14-ST-3,5 1914056 PHOENIX CONTACT PCB terminal block View larger
Images are for illustrative purposes only. Please refer to data sheet for details

FK-MPT 0,5/14-ST-3,5 1914056 PHOENIX CONTACT PCB terminal block

FK-MPT 0,5/14-ST-3,5

1914056

PHOENIX CONTACT

50 Pcs.

PCB terminal block Connector for printed circuit board, nominal section: 0.5 mm², color: green, nominal current: 4 A, nominal voltage (III/2): 250 V, contact surface: Tin, contact type: Female, number of potentials: 14, number of rows: 1, number of poles: 14, number of connections: 28, article family: FK-MPT 0.5/.. -ST, pitch: 3.5mm, connection type: Push-in spring connection, driver/printed circuit board connection direction: 0°, plug-in system: COMBICON PST 1.0, lock: without, fixing type: without, packaging type: boxed

Cables > Cable connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1914056
Packing unit50 pc
Minimum order quantity50 pc
NoteMade to Order (non-returnable)
Catalog pagePage 403 (C-1-2013)
GTIN4017918176952
Weight per Piece (excluding packing)4.730 g
Custom tariff number85366990
Country of originDE (Germany)

Dimensions

Length [ l ]9.5 mm
Width [ w ]49.5 mm
Height [ h ]8.5 mm
Pitch3.5 mm
Dimension a45.5 mm

General

Range of articlesFK-MPT 0,5/..-ST
Number of positions14
Connection methodPush-in spring connection
Insulating material groupIIIa
Rated surge voltage (III/3)2.5 kV
Rated surge voltage (III/2)2.5 kV
Rated surge voltage (II/2)2.5 kV
Rated voltage (III/3)160 V
Rated voltage (III/2)250 V
Rated voltage (II/2)250 V
Connection in acc. with standardEN-VDE
Nominal current IN4 A
Nominal cross section0.5 mm²
Maximum load current4 A (with 0.5 mm² conductor cross section)
Insulating materialPBT
Flammability rating according to UL 94V0
Stripping length6.5 mm

Connection data

Conductor cross section solid min.0.12 mm²
Conductor cross section solid max.0.5 mm²
Conductor cross section AWG min.26
Conductor cross section AWG max.20
Minimum AWG according to UL/CUL28
Maximum AWG according to UL/CUL20

Standards and Regulations

Connection in acc. with standardEN-VDE
CUL
Flammability rating according to UL 94V0

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
