PHOENIX CONTACT PLH 16/ 2-15 MIX BK/RD PLH 16/ 2-15 MIX BK/RD 1703268 PHOENIX CONTACT PCB terminal block View larger
Images are for illustrative purposes only. Please refer to data sheet for details

PLH 16/ 2-15 MIX BK/RD 1703268 PHOENIX CONTACT PCB terminal block

PLH 16/ 2-15 MIX BK/RD

1703268

PHOENIX CONTACT

25 Pcs.

PCB terminal block Terminal block for printed circuit board, nominal current: 76 A, dimensioning voltage (III/2): 1000 V, nominal cross-section: 16 mm², Number of potentials: 2, Number of rows: 1, Number of poles per row: 2, article family: PLH 16/, pitch: 15 mm, connection type: Spring push lock connection, mounting: Wave soldering, conductor connection direction/printed circuit board: 0 °, color: multicolor, Pin arrangement: Double linear pin arrangement, Pin length [P]: 4.5 mm, packaging type: boxed

Connectors > Printed circuit board terminal
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1703268
Packing unit1
GTIN4046356646628
Custom tariff number85369010

Dimensions

Length [ l ]30.5 mm
Pitch15 mm
Dimension a15 mm
Width [ w ]26.4 mm
Height33.5 mm
Height [ h ]29 mm
Solder pin [P]4.5 mm
Pin spacing12.5 mm
Hole diameter1.6 mm

General

Range of articlesPLH 16/
Insulating material groupI
Rated surge voltage (III/3)8 kV
Rated surge voltage (III/2)8 kV
Rated surge voltage (II/2)8 kV
Rated voltage (III/3)1000 V
Rated voltage (III/2)1000 V
Rated voltage (II/2)1000 V
Nominal current IN76 A
Nominal cross section16 mm²
Insulating materialPA
Solder pin surface
Flammability rating according to UL 94V0
Stripping length18 mm
Number of positions2

Connection data

Conductor cross section solid min.0.75 mm²
Conductor cross section solid max.16 mm²
Conductor cross section flexible min.0.75 mm²
Conductor cross section flexible max.25 mm²
Conductor cross section AWG min.18
Conductor cross section AWG max.4
2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, min.0.75 mm²
2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, max.4 mm²

Standards and Regulations

Flammability rating according to UL 94V0

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
