PHOENIX CONTACT PT 2,5/ 2-5,0-H PT 2,5/ 2-5,0-H 1935776 PHOENIX CONTACT Screw compact terminal block View larger
Images are for illustrative purposes only. Please refer to data sheet for details

PT 2,5/ 2-5,0-H 1935776 PHOENIX CONTACT Screw compact terminal block

PT 2,5/ 2-5,0-H

1935776

PHOENIX CONTACT

250 Pcs.

Screw compact terminal block Terminal block for printed circuit board, nominal current: 32 A, nominal voltage (III/2): 400 V, nominal section: 2.5 mm², number of potentials: 2, number of rows: 1, number of poles per row: 2, family of articles: PT 2.5/.. -H, pitch: 5 mm, connection type: Screw connection with wire protection bracket, screw clamping form: H1L Philipps-Recess with longitudinal slot, mounting: Wave soldering, conductor/printed circuit board connection direction: 0 °, color: green, Pin arrangement: Linear pin arrangement, Pin length [P]: 4.1 mm, number of solder pins per potential: 1, Packing type: Boxed packed. In case of using ferrules, 250 V is only reached in combination with the surge category / the dirt grade II/2.

Connectors > Printed circuit board terminal
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1935776
Packing unit250 pc
Minimum order quantity250 pc
Catalog pagePage 427 (C-1-2013)
GTIN4017918948399
Weight per Piece (excluding packing)2.410 g
Custom tariff number85369010
Country of originPL (Poland)

Item properties

Brief article descriptionPCB terminal block
Range of articlesPT 2,5/..-H
Pitch5 mm
Number of positions2
Connection methodScrew connection with wire protector
Drive form screw headPhilipps recess with slotted Torx
Screw threadM3
Mounting typeWave soldering
Pin layoutLinear pinning
Number of levels1
Number of connections2
Number of potentials2

Electrical parameters

Rated current32 A
Rated insulation voltage (III/2)400 V
Rated surge voltage (III/2)4 kV

Connection capacity

Conductor cross section solid0.5 mm² ... 4 mm²
Conductor cross section flexible0.5 mm² ... 4 mm²
Conductor cross section AWG / kcmil20 ... 10
Conductor cross section flexible, with ferrule without plastic sleeve0.5 mm² ... 2.5 mm²
Conductor cross section, flexible, with ferrule, with plastic sleeve0.5 mm² ... 2.5 mm²
2 conductors with same cross section, solid0.5 mm² ... 1.5 mm²
2 conductors with same cross section, flexible0.5 mm² ... 1.5 mm²
2 conductors with same cross section, stranded, ferrules without plastic sleeve0.5 mm² ... 0.75 mm²
2 conductors with same cross section, stranded, with TWIN ferrules with plastic sleeve0.5 mm² ... 1.5 mm²
Stripping length6.5 mm
Torque0.45 Nm ... 0.5 Nm

Material data - contact

NoteWEEE/RoHS-compliant, free of whiskers according to IEC 60068-2-82/JEDEC JESD 201
Contact materialCu alloy
Metal surface terminal point (top layer)Tin (3 - 12 µm Sn)
Metal surface terminal point (middle layer)Nickel (1.5 - 4 µm Ni)
Metal surface soldering area (top layer)Tin (3 - 12 µm Sn)
Metal surface soldering area (middle layer)Nickel (1.5 - 4 µm Ni)

Material data - housing

Insulating materialPA
Insulating material groupI
CTI according to IEC 60112850
Flammability rating according to UL 94V0
Glow wire flammability index GWFI according to EN 60695-2-12850
Glow wire ignition temperature GWIT according to EN 60695-2-13775
Temperature for the ball pressure test according to EN 60695-10-2125 °C

Dimensions for the product

Dimensional drawing
Length [ l ]9 mm
Width [ w ]10 mm
Height [ h ]17.6 mm
Pitch5 mm
Height (without solder pin)13.5 mm
Solder pin [P]4.1 mm
Pin spacing5 mm
Pin dimensionsø 1 mm
Dimension a5 mm

Dimensions for PCB design

Hole diameter1.3 mm
Pin spacing5 mm

Packaging information

Type of packagingpacked in cardboard
Pieces per package250
Denomination packing unitsPcs.

General product information

Type of noteNote on application
NoteFor safe conductor connection, always adhere to a defined tightening torque. Particularly in the case of PCB terminal blocks with two or three positions, the individual solder pin for each contact point cannot compensate for this. That is why the terminal blocks must be supported during conductor connection (held with one hand, support on the housing).

Ambient conditions

Ambient temperature (storage/transport)-40 °C ... 70 °C
Ambient temperature (assembly)-5 °C ... 100 °C
Ambient temperature (operation)-40 °C (Depending on the current carrying capacity/derating curve)

Electrical tests

Rated current32 A
Rated insulation voltage (III/2)400 V
Rated surge voltage (III/2)4 kV

Air clearances and creepage distances

Insulating material groupI
Rated insulation voltage (III/3)250 V
Rated insulation voltage (III/2)400 V
Rated insulation voltage (II/2)630 V
Rated surge voltage (III/3)4 kV
Rated surge voltage (III/2)4 kV
Rated surge voltage (II/2)4 kV

Standards and Regulations

Connection in acc. with standardEN-VDE
CUL
Flammability rating according to UL 94V0

Environmental Product Compliance

China RoHSEnvironmentally Friendly Use Period = 50
For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration”
