PHOENIX CONTACT PTDA 2,5/ 3-5,0 GNYE PTDA 2,5/ 3-5,0 GNYE 1710785 PHOENIX CONTACT PCB terminal block

View larger

Images are for illustrative purposes only. Please refer to data sheet for details

PTDA 2,5/ 3-5,0 GNYE 1710785 PHOENIX CONTACT PCB terminal block

Name: PTDA 2,5/ 3-5,0 GNYE 1710785 PHOENIX CONTACT PCB terminal block
Brand: PHOENIX CONTACT
SKU: 1710785

Reference: PTDA 2,5/ 3-5,0 GNYE

Code: 1710785

Manufacturer: PHOENIX CONTACT

Units per package: 50 Pcs.

Description:

PCB terminal block Terminal block for printed circuit board, nominal current: 24 A, dimensioning voltage (III/2): 400 V, nominal cross-section: 2.5 mm², Number of rows: 1, Number of poles per row: 3, article family: PTDA 2.5/, pitch: 5 mm, connection type: Push-in spring connection, mounting: Wave soldering, conductor connection direction/printed circuit board: 45°, color: green-yellow, Pin arrangement: Double linear pin arrangement, Pin length [P]: 3.5mm, Packaging type: boxed

Categories:
Connectors > Printed circuit board terminal
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Guarantee, repair and return.

More info

▲

Key Commercial Data

Orderkey	1710785
Packing unit	50 pc
Minimum order quantity	50 pc
Note	Made to Order (non-returnable)
GTIN	4055626177236
Weight per Piece (excluding packing)	5.120 g
Custom tariff number	85369010
Country of origin	PL (Poland)

Dimensions

Pitch	5 mm
Solder pin [P]	3.5 mm
Pin spacing	5 mm
Hole diameter	1.3 mm

General

Range of articles	PTDA 2,5/
Insulating material group	I
Rated voltage (III/2)	400 V
Nominal current I_N	24 A
Nominal cross section	2.5 mm²
Solder pin surface
Flammability rating according to UL 94	V0
Number of positions	3
