PC 6/ 2-G-7,62 BK

1097707

PHOENIX CONTACT

50 Pcs.

PCB headers, nominal current: 41 A, rated voltage (III/2): 630 V, nominal cross section: 6 mm², number of positions: 2, pitch: 7.62 mm, color: black, contact surface: Tin, mounting: Wave soldering, pin layout: Linear pinning, solder pin [P]: 2.6 mm Printed circuit board base case, nominal section: 6 mm², color: black, nominal current: 41 A, nominal voltage (III/2): 630 V, contact surface: Tin, contact type: Male, number of rows: 1, number of poles: 2, family of articles: PC 6/.. -G, pitch: 7.62 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 2.6 mm, number of solder pins per potential: 3, plug-in system: COMBICON PC 6, Plug-in face orientation: Standard, lock: without, fixing type: without, packaging type: boxed

Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1097707
Packing unit1 pc
Minimum order quantity50 pc
GTIN4055626937960
Weight per Piece (excluding packing)5.600 g
Custom tariff number85366930
Country of originCN (China)

Item properties

Brief article descriptionFeed-through header
Plug-in systemPOWER COMBICON 6
Type of contactMale connector
Range of articlesPC 6/..-G
Pitch7.62 mm
Number of positions2
Mounting typeWave soldering
Pin layoutLinear pinning
Number of levels1
1
Back to top

Electrical parameters

Nom. voltage630 V
Back to top

Material data - contact

NoteWEEE/RoHS-compliant, free of whiskers according to IEC 60068-2-82/JEDEC JESD 201
Contact materialCu alloy
Surface characteristicsTin-plated
Metal surface contact area (top layer)Tin (2 - 4 µm Sn)
Metal surface contact area (middle layer)Nickel (1.3 - 3 µm Ni),
Metal surface soldering area (top layer)Tin (2 - 4 µm Sn)
Metal surface soldering area (middle layer)Nickel (1.3 - 3 µm Ni)
Back to top

Material data - housing

Insulating materialPA GF
Insulating material groupI
CTI according to IEC 60112600
Flammability rating according to UL 94V0
Back to top

Dimensions for the product

Length [ l ]28.2 mm
Width [ w ]15.64 mm
Height [ h ]16.1 mm
Pitch7.62 mm
Height (without solder pin)13.5 mm
Solder pin [P]2.6 mm
Pin dimensions1 x 1.2 mm
Dimension a7.62 mm
Back to top

Dimensions for PCB design

Hole diameter1.7 mm
Back to top

Packaging information

Type of packagingpacked in cardboard
Pieces per package50
Denomination packing unitsPcs.
Back to top

Ambient conditions

Ambient temperature (storage/transport)-40 °C ... 70 °C
Ambient temperature (assembly)-5 °C ... 100 °C
Ambient temperature (operation)-40 °C ... 100 °C (dependent on the derating curve)
Back to top

Air clearances and creepage distances

Clearances and creepage distancesIEC 60664-1:2007-04
SpecificationIEC 60664-1:2007-04
Rated insulation voltage (III/3)630 V
Rated insulation voltage (III/2)630 V
Rated insulation voltage (II/2)1000 V
Rated surge voltage (III/3)6 kV
Rated surge voltage (III/2)6 kV
Rated surge voltage (II/2)6 kV
Minimum clearance - inhomogeneous field (III/3)5.5 mm
Minimum clearance - inhomogeneous field (III/2)5.5 mm
Minimum clearance - inhomogeneous field (II/2)5.5 mm
Minimum creepage distance value (III/3)8 mm
Minimum creepage distance value (III/2)3.2 mm
Minimum creepage distance value (II/2)5 mm
Back to top

Classifications

eCl@ss

eCl@ss 8.027440402
eCl@ss 9.027440402
Back to top

ETIM

ETIM 5.0EC002637
ETIM 6.0EC002637
ETIM 7.0EC002637
Back to top

ETIM for 1097707 Connectors (EC002637)
Feature Name Feature Value
Connector model (EF007495) Fixed connector
Contact type (EF001587) Pin
Number of plug-in contact rows (EF006935) 1
Modular spacing contacts (EF007326) 7.62 mm
Modular spacing connections (EF006827) 7.62 mm
Rated current In (EF008250) 41 A
Rated voltage (EF000228) 630 V
Rated surge voltage (EF002993) 6 kV
Over voltage category (EF006785) III
Pollution degree (EF006786) 2
Material of contact surface (EF004020) Tin
Type of electric connection (EF003961) Other
Diameter connection pin (EF006823) 1.7 mm
Length pin (EF006825) 2.6 mm
Housing colour (EF000136) Black
Inflammability class of insulation material according to UL94 (EF002521) V0
Operating temperature (EF002393) -40 °C
Type of fastening (EF002442) Other
Type of banding (EF007011) Carton (for SMD)
