PHOENIX CONTACT PC 6-16/ 4-G-10,16 BK PC 6-16/ 4-G-10,16 BK 1708378 PHOENIX CONTACT Feed-through header View larger
Images are for illustrative purposes only. Please refer to data sheet for details

PC 6-16/ 4-G-10,16 BK 1708378 PHOENIX CONTACT Feed-through header

PC 6-16/ 4-G-10,16 BK

1708378

PHOENIX CONTACT

1 Pcs.


Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Feed-through header

Base housing printed circuit board, nominal section: 6 mm², color: black, rated current: 76 A (41 A in combination with PC 6 connector), sizing voltage (III/2): 1000 V, surface contacts: silver, contact type: Male, Number of potentials: 4, Number of rows: 1, Number of poles per row: 4, number of connections: 4, Item family: PC 6-16/.. -G, pitch: 10.16 mm, mounting: Wave welding, pin arrangement: Triple linear pin arrangement, pin length [P]: 5 mm, Stecksystem: POWER COMBICON 16, Locking: sin, packing type: boxed packaging

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
