PC 6-16/ 2-G1FU-10,16 BK 1715924 PHOENIX CONTACT Housing base printed circuit board, number of poles: 2, pit..
PC 6-16/ 2-G1FU-10,16 BK
1715924
PHOENIX CONTACT
50 Pcs.
Housing base printed circuit board, number of poles: 2, pitch: 10,16 mm, color: black, surface of contacts: silver, assembly: wave Soldering
Printed circuit board base housing, nominal section: 16 mm², color: black, nominal current: 76 A (41 A in combination with PC 6 connector), nominal voltage (III/2): 1000 V, contact surface: silver, contact type: Male, number of potentials: 2, number of rows: 1, number of poles: 2, number of connections: 2, family of articles: PC 6-16/.. -G1FU, pitch: 10.16 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 4 mm, number of solder pins per potential: 3, plug-in system: COMBICON PC 16, Plug-in face orientation: inverted, locking: Screw lock, fixing type: Air clamping (thread), packaging type: boxed
Connectors > Printed circuit board connector
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Housing base printed circuit board, nominal current: 76 A, voltage and sizing (III/2): 1000 V, number of poles: 2, pitch: 10,16 mm, color: black, surface of contacts: silver, assembly: wave Soldering
Data commercial
| Key order | One million seven hundred fifteen thousand nine hundred twenty four |
|---|---|
| Packing unit | 50 pcs |
| Key selling | AABEBA - |
| Minimum order quantity | 50 pcs |
| EAN | Four trillion fifty five billion six hundred twenty six million four hundred sixty three thousand four hundred ninety |
| Unit weight (excluding packaging) | 14,616 g |
| Tariff number tariff | Eighty five million three hundred sixty six thousand nine hundred thirty |
Dimensions
| Length [ l ] | 34 mm |
|---|---|
| Width | 38,08 mm |
| Step | 10,16 mm |
| Average | 10,16 mm |
| Width [ w ] | 38,08 mm |
| Height [ h ] | 13,4 mm |
| Height of construction | 17,4 mm |
| Length of the pin welding | 4 mm |
| Dimensions of pin | 0.8 x 1.2 mm |
| Separation between rods | 10,16 mm |
| Length | 34 mm |
Overview
| Family of articles | PC 6-16/..-G1FU |
|---|---|
| Color | black |
| Number of poles | Two |
Environmental Product Compliance
| China RoHS | Space of time for the intended use: unlimited = FEUP-e |
|---|---|
| No dangerous substances above the thresholds |
Ratings
eCl@ss
| eCl@ss 5.1 | Twenty seven million two hundred sixty thousand seven hundred |
|---|---|
| eCl@ss 6.0 | Twenty seven million two hundred sixty thousand seven hundred |
| eCl@ss 7.0 | Twenty seven million four hundred forty thousand four hundred two |
| eCl@ss 8.0 | Twenty seven million four hundred forty thousand four hundred two |
| eCl@ss 9.0 | Twenty seven million four hundred forty thousand four hundred two |
ETIM
| ETIM 5.0 | EC002637 |
|---|---|
| ETIM 6.0 | EC002637 |
| ETIM 7.0 | EC002637 |
| Feature Name | Feature Value |
|---|---|
| Connector model (EF007495) | Fixed connector |
| Contact type (EF001587) | Pin |
| Number of poles (EF001391) | 2 |
| Number of plug-in contact rows (EF006935) | 1 |
| Modular spacing contacts (EF007326) | 10.16 mm |
| Modular spacing connections (EF006827) | 10.16 mm |
| Rated current In (EF008250) | 76 A |
| Rated voltage (EF000228) | 1000 V |
| Rated surge voltage (EF002993) | 8 kV |
| Over voltage category (EF006785) | III |
| Pollution degree (EF006786) | 2 |
| Material of contact surface (EF004020) | Silver |
| Type of electric connection (EF003961) | Other |
| Diameter connection pin (EF006823) | 1.7 mm |
| Length pin (EF006825) | 4 mm |
| Material insulation body (EF007543) | Other |
| Housing colour (EF000136) | Black |
| Inflammability class of insulation material according to UL94 (EF002521) | V0 |
| Operating temperature (EF002393) | -40 °C |
| Type of fastening (EF002442) | Other |
| Type of banding (EF007011) | Carton (for SMD) |
