PHOENIX CONTACT PLH 16/ 3-15 BD:2T1-6T3 PLH 16/ 3-15 BD:2T1-6T3 1712964 PHOENIX CONTACT PCB terminal block View larger
Images are for illustrative purposes only. Please refer to data sheet for details

PLH 16/ 3-15 BD:2T1-6T3 1712964 PHOENIX CONTACT PCB terminal block

PLH 16/ 3-15 BD:2T1-6T3

1712964

PHOENIX CONTACT

25 Pcs.

PCB terminal block Terminal block for printed circuit board, nominal current: 76 A, dimensioning voltage (III/2): 1000 V, nominal cross-section: 16 mm², Number of potentials: 3, Number of rows: 1, Number of poles per row: 3, article family: PLH 16/, pitch: 15 mm, connection type: Spring push lock connection, mounting: Wave soldering, conductor connection direction/printed circuit board: 0°, color: green, Pin arrangement: Double linear pin arrangement, Pin length [P]: 4.5 mm, packaging type: boxed

Connectors > Printed circuit board terminal
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1712964
Packing unit1
GTIN4055626345529
Custom tariff number85369010

Dimensions

Length [ l ]30.5 mm
Pitch15 mm
Dimension a30 mm
Width [ w ]41.4 mm
Height33.5 mm
Height [ h ]29 mm
Solder pin [P]4.5 mm
Pin spacing12.5 mm
Hole diameter1.6 mm

General

Range of articlesPLH 16/
Insulating material groupI
Rated voltage (III/2)1000 V
Nominal current IN76 A
Nominal cross section16 mm²
Solder pin surface
Flammability rating according to UL 94V0
Number of positions3

Standards and Regulations

Flammability rating according to UL 94V0

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
